For more information about where to send your waste equipment for recycling, please contact your local city office, your household waste disposal service or where you purchased the product. NP-3262 POS Terminal ...
Page 3
The material in this document is for information purpose and is subject to change without prior notice. APPOSTAR has made every effort to ensure that this user’s manual is accurate and complete. However, no liability is assumed for any errors and omissions that may have occurred.
6. Do not place heavy objects on top of the product or lean them against the product. These items may fall down and cause injury. 7. Do not block the air vent of the product as this can cause heat accumulation inside the box machine and may cause a fire. NP-3262 POS Terminal ...
1. POS S Termina l Main Un . Power A Adapter 3. Power c cord (ord dered spe ecification) 4. Quic ck Refere nce Guide 5. Drive r CD (User r’s Manua l included NP-3262 PO OS Termina ...
PRODUCT OVERVIEW 1.2 Appearance Front View 15” LCD touch panel MSR module (option) / Attachable on both sides Front panel Base Rear View Hinge cover Power button I/O Cover Stand cover NP-3262 POS Terminal...
Page 9
LAN po ort with RJ SPEAK speake er x 2 NOTE: To avoid c confusion with the L LAN port, the COM 2 is prote ected with a lid. Remove the lid be efore use. NP-3262 P POS Termin...
Finger Print 512dpi x 8bit gray scale; Capture area: 14.6 x 18.1 mm i-button Dallas Key Wireless LAN 802.11 b/g Customer Display VFD/LCD customer display Powering Power Supply AC 100V~240V/60W power adapter ( 90W optional ) NP-3262 POS Terminal ...
Page 11
Storage Temperature -20°C ~ 60°C Operating Humidity 15%~80% RH Storage Humidity 20% ~90% RH Mechanical Housing Color Cool White, Dark Gray Construction ABS + SECC Dimension (W x D x H) 390 x 235 x 320 mm Weight N.W. 5.7 kg NP-3262 POS Terminal...
2.1 Magnetic Stripe Reader (MSR) Installation An optional MSR can be installed on both the right and left side of NP-3262. By default, the MSR is installed on the right side.
Step 3 T Tear off th he small p art of rub bber (as sh hown in th he picture e below). There is an open ing on the e hinge fo or cable ro outing. NP-3262 P POS Termin...
Page 14
Step 5 Route the RJ45 signal cable through an opening on the hinge. Step 6 Fit the VFD/LCD display panel with bracket in position and refasten them with 2 screws. Step 7 Reinstall the hinge cover with 2 screws. NP-3262 POS Terminal ...
Page 15
I/O c cover. Step 10 Reinstall the I/O co over and the stand d cover wi th 1 thum mb screw. NP-3262 P POS Termin...
Microsoft Windows platforms. Insert the driver CD into your CD-ROM drive. Windows will automatically detect it and the Appostar Driver Installer appears on the screen. If not, locate the Setup.exe file at CD:\ and double-click it to execute the one-step driver installation.
Page 17
No to continue. g. Select “Install this driver h. Select “Install” in Windows Security software anyway” in Windows window to continue the installation Security window to continue the procedure. installation procedure. i. Select “Yes” to reboot system. NP-3262 POS Terminal...
Double-click Touch Panel. b. Click Next on the Welcome screen to continue. c. Ignore the “Install PS/2 interface d. Select the “Install RS232 interface driver” option. Click Next to driver” option. Click Next to continue. continue. NP-3262 POS Terminal ...
Page 19
Select the Destination Folder or use h. Type a Folder name or use the the default one listed. default one listed. Click Next to continue. i. A progress window appears. Please j. Click Yes. The installation wait. completes in seconds. NP-3262 POS Terminal...
6. Reset your desired password or clear the CMOS data. JPC1/3/4/5/6: Voltage Switch jumper for JCOM1/3/4/5/6 ports This header is for controlling the Pin9 of COM ports to switch Ring/ 5V/12V. Pin 5-6 Close: Pin 1-2 Close: Pin9=12V Pin9=5V Pin 3-4 Close: Pin9=Ring (Default) Remark: Max output: 12V@500mA for each COM port NP-3262 POS Terminal ...
Page 21
Max output: 12V@500mA for each COM port JCOM2: Serial Port Connector Assignment COM2_RI COM2C_DSR COM2C_TXD COM2C_RXD COM2C_RTS COM2C_CTS COM2C_DTR ATTENTION To avoid system malfunctions, DO NOT change the default setting by yourself. Contact your dealer for assistance if needed. NP-3262 POS Terminal...
Navigation Keys for that particular menu are at the bottom right corner, General Help and you can use these keys to select item and change Navigation Keys the settings. NP-3262 POS Terminal ...
Page 23
The content of this manual is subject to be changed without notice. We will not be responsible for any mistakes found in this user’s manual and any system damage that may be caused by wrong-settings. NP-3262 POS Terminal...
Total Memory Shows the system memory size, VGA shard memory will be excluded.. System Time Set the system internal clock. System Date Set the system date. Note that the ‘Day’ automatically changes when you set the date. NP-3262 POS Terminal ...
Beware of that setting inappropriate values in items of this menu may cause system to malfunction. Launch Storage OpROM This item allows you to enable or disable Boot Option for Legacy Mass Storage Devices with Option ROM. Options: Enabled (Default) / Disabled NP-3262 POS Terminal...
Page 26
Disabled (Default) / Enabled PERR# Generation This item enables or disables PCI Device to generate PERR#. Options: Disabled (Default) / Enabled SERR# Generation This item enables or disables PCI Device to generate SERR#. Options: Disabled (Default) / Enabled NP-3262 POS Terminal ...
Page 27
This item selects the highest ACPI sleep state the system will enter when the SUSPEND button is pressed. Options: S1 (CPU Stop Clock) (Default) / Suspend Disabled Lock Legacy Resources This item enables or disables Lock of Legacy Resources. Options: Disabled (Default) / Enabled PME Wake up from S5 NP-3262 POS Terminal...
Page 28
When EuP is enabled, the system will meet EuP requirement. Options: Disabled (Default) / Enabled Ring-In Wake up from S5 This item enables the system to wake from S5 using Ring-In event. Options: Disabled (Default) / Enabled NP-3262 POS Terminal ...
Page 29
Before it can do so, it must first query the processor to find out the highest input value CPUID recognizes. This determines the kind of basic information CPUID can provide the operating system. Options: Disabled (Default) / Enabled NP-3262 POS Terminal...
Page 30
This item enables/disables Serial ATA Controller (s). Options: Enabled (Default) / Disabled Configure SATA as This item selects a configuration for SATA controller. Options: IDE (Default) / AHCI SATA Port1 Options: Enabled (Default) / Disabled SATA Port2 Options: Enabled (Default) / Disabled NP-3262 POS Terminal ...
Page 31
20 sec (Default) / 1 sec / 5 sec / 10 sec Device reset time-out This is the USB mass storage device Start Unit command time-out. Options: 20 sec (Default) / 10 sec / 30 sec / 40 sec NP-3262 POS Terminal...
Page 32
5 (Default) / 1 ~ 40 SMART FAN Control CPU Smart FAN This item is CPU FAN Smart control function.[Disabled]:Full ON [Auto]:By parameters below. Options: Disabled(Default) / Auto CPU FAN Calibrate Press [Enter] to Calibrate CPU FAN. NP-3262 POS Terminal ...
Page 33
RPM. FAN Ctrl ON(℃):When temperature is higher than this value,the fan controller will turn on. FAN Ctrl Start Value:Set FAN Start Speed Value. FAN Ctrl Sensltive:SMART FAN Control. Options: Quiet / Aggressive / Manual(Default) Super IO Configuration NP-3262 POS Terminal...
Printer Port) / EPP Mode (Using Parallel Port as Enhanced Parallel Port) / ECP Mode (Using Parallel port as Extended Capabilities Port) / EPP Mode & ECP Mode (Using Parallel port as ECP & EPP mode) NP-3262 POS Terminal ...
Page 37
Power Off (Default) / Power On / Last State Watch Dog Degree This item allows you to determine the functional degree of Watch Dog. Options: Second (Default) / Minute Watch Dog Timer Options: 0 for disabled (Default) / Min=1, Max=65536 H/W Monitor NP-3262 POS Terminal...
Page 38
BIOS SETTING F81216 Second Super IO Configuration NP-3262 POS Terminal ...
Page 39
This item enables or disables Serial Port (COM). Options: Enabled (Default) / Disabled Change Settings This item allows you to select an optimal setting for Super IO device. Options: IO=3E8h; IRQ=5 (Default) / IO=2E8h; IRQ=5 / IO=2F0h; IRQ=5 / IO=2E0h; IRQ=5 NP-3262 POS Terminal...
Page 40
This item enables or disables Serial Port (COM). Options: Enabled (Default) / Disabled Change Settings This item allows you to select an optimal setting for Super IO device. Options: IO=2E8h; IRQ=5 (Default) / IO=3E8h; IRQ=5 / IO=2F0h; IRQ=5 / IO=2E0h; IRQ=5 NP-3262 POS Terminal ...
Page 41
This item enables or disables Serial Port (COM). Options: Enabled (Default) / Disabled Change Settings This item allows you to select an optimal setting for Super IO device. Options: IO=2F0h; IRQ=5 (Default) / IO=3E8h; IRQ=5 / IO=2E8h; IRQ=5 / IO=2E0h; IRQ=5 NP-3262 POS Terminal...
Page 42
IO=2E0h; IRQ=5 (Default) / IO=3E8h; IRQ=5 / IO=2E8h; IRQ=5 / IO=2F0h; IRQ=5 / UART IRQ Mode This item allows you to determine the PCI IRQ Sharing for OS (ex. Windows) or ISA IRQ for DOS. Options: PCI IRQ Sharing (Default) / ISA IRQ NP-3262 POS Terminal ...
Page 43
This item controls a programmable time for the CPU voltage to stabilize when exiting from a C4 state. Options: Fast (Default) / Default / Slow C-state POPDOWN When this item is disabled, it prevents automatic return to a previous C3 or C4 state. Options: Enabled (Default) / Disabled NP-3262 POS Terminal...
Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed of the CPU itself uses when communicating with its own special components. Notice Beware of that setting inappropriate values in items of this menu may cause system to malfunction. NP-3262 POS Terminal ...
Page 47
Auto (Default) / Force Scaling / Off / 1Maintain Aspect Ratio Active LVDS This item selects the Active LVDS Configuration. No LVDS: VBIOS does not enable LVDS; Int-LVDS: VBIOS enables LVDS driver by Integrated encoder. Options: Int-LVDS (Default) / No LVDS Fixed Graphics Memory Size NP-3262 POS Terminal...
Page 48
BIOS SETTING This item configures the Fixed Graphics Memory Size. Options: 128MB (Default) / 256MB South Bridge NP-3262 POS Terminal ...
Page 49
Azalia supports 1 extended VC, which will override ICH VCp settings when enabled. Options: Enabled (Default) / Disabled Select USB Mode This item selects USB mode to control USB ports. Options: By Controllers (Default) / By Ports NP-3262 POS Terminal...
Page 50
This item enables or disables the High Precision Event Timer. Options: Enabled (Default) / Disabled SLP_S4 Assertion Width This item selects a minimum assertion width of the SLP_S4# signal. Options: 1-2 Seconds (Default) / 2-3 Seconds / 3-4 Seconds / 4-5 Seconds NP-3262 POS Terminal ...
ALWAYS – it doesn’t allow disabling the GA20; this option is useful when any code is executed above 1MB. Options: Upon Request (Default) / Always Option ROM Messages This item can set the display mode for Option ROM. Options: Force BIOS (Default) / Keep Current NP-3262 POS Terminal...
Page 52
The BIOS will attempt to arrange the hard disk boot sequence automatically. can also change the booting sequence. The number of device items that appears on the screen depends on the number of devices installed in the system. NP-3262 POS Terminal ...
BIOS SETTING 5.5 Security Menu This menu allows you to provide/revise supervisor and user password. Administrator Password This item sets Administrator Password. User Password This item sets User Password. NP-3262 POS Terminal...
This selection allows you to reload the BIOS when problem occurs during system booting sequence. These configurations are factory settings optimized for this system. Boot Override This item allows you to exit the system setup without saving any changes. NP-3262 POS Terminal ...
<Enter>: Exits the menu, saves changes, and boots from the selected device <Esc>: Exits the menu without saving changes ATTENTION To avoid system malfunctions, DO NOT change the BIOS default setting by yourself. Contact your dealer for assistance if needed. NP-3262 POS Terminal...
Chapter 6 TROUBLESHOOTING This chapter provides suggestions on how to locate and solve problems that may arise while using your NP-3262. If you cannot solve a problem with the following information, contact your dealer for further assistance. With the power on, there is no image or abnormal display on the terminal screen.
APPENDIX APPENDIX Magnetic Stripe Reader (MSR) Installation An optional MSR can be installed in both right/left side of NP-3262. By default, the MSR is installed on the right side. Step 1 Remove the cover from the MSR extension slot.
