Daewoo KOM-9F2CTS Service Manual

0.9 cu.ft
Hide thumbs
Table of Contents

Advertisement

Quick Links

S/M No. :
Service Manual

Microwave Oven

Model: KOM-9F2CTS
KOM-9F2CKS
Caution
: In this Manual, some parts can be changed for improving,
their performance without notice in the parts list. So, if you
need the latest parts information, please refer to PPL(Parts
Price List) in Service Information Center (http://svc.dwe.co.kr).
May. 2012

Advertisement

Table of Contents
loading

Related Manuals for Daewoo KOM-9F2CTS

Summary of Contents for Daewoo KOM-9F2CTS

  • Page 1: Microwave Oven

    S/M No. : Service Manual Microwave Oven Model: KOM-9F2CTS KOM-9F2CKS Caution : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).

  • Page 2: Table Of Contents

    PRECAUTIONS TO BE OBSERVED BEFORE AND DURING SERVICING TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not operate or allow the oven to be operated with the door open. (b) Make the following safety checks on all ovens to be serviced before activating the magnetron or other microwave source, and make repairs if necessary: (1) Interlock operation, (2) Proper door closing, (3) Seal and sealing surfaces (arcing, wear, and other damage), (4) Damage to or loosening of hinges and latches (5) Evidence of dropping or abuse.

  • Page 3: Safety And Precautions

    SAFETY AND PRECAUTIONS CAUTION : This Device is to be Serviced Only by Properly Qualified Service Personnel. Consult the Service Manual for Proper Service Procedures to Assure Continued Safety Operation and for Precautions to be Taken to Avoid Possible Exposure to Excessive Microwave Energy. 1.

  • Page 4: Specifications

    SPECIFICATIONS MODEL KOM-9F2CTS KOM-9F2CKS POWER SUPPLY 240V AC 50Hz SINGLE PHASE WITH EARTHING POWER CONSUMPTION 3000W 2600W MICROWAVE OUTPUT POWER 1850W 1500W FREQUENCY 2450Mhz 2450Mhz OUTSIDE DIMENSIONS (W X H X D) 465 X 370 X 599 mm ( 18.31 X 14.57 X 23.58 in.) CAVITY DIMENSIONS (W X H X D) 371 X 198.5 X 372 mm ( 14.61 X 7.81 X 14.66 in.)

  • Page 5: External View

    EXTERNAL VIEW 1. OUTER DIMENSION...

  • Page 6: Features Diagram

    2. FEATURE DIAGRAM 1 Safety Interlock System. 5 Door Seal - Door seal maintains the microwave energy within the oven cavity and prevents 2 Door Viewing Screen - Allows viewing of food. microwave leakage. The screen is designed so that light can pass 6 Plate Tray - Made of special heat resistant through, but not the microwave.

  • Page 7: Control Panel

    3. CONTROL PANEL 1 MICROWAVE indicator 8 DOUBLE QUANTITY pad It will turn on when the magnetron output actually X2 pad increases a preprogrammed cooking is on. time by a percentage of the original cooking time. The user specifies the percentage and it can be 2 Double Quantity indicator changed for individual cooking sequences.

  • Page 8: Installation

    INSTALLATION 1. Steady, flat location. This microwave oven should be set on a steady, flat surface. 2. Leave space behind and side. All air vents should be kept clear. If all vents are covered during operation, the oven may be overheated and, eventually, cause oven failure.

  • Page 9: Operations And Functions

    OPERATIONS AND FUNCTIONS 1. Connect the mains lead to an electrical outlet. 2. Open the oven door once to use the oven. The display lights up and the oven is ready to work. 3. After placing the food in a suitable container, open the oven door and put it in the cavity. 4.

  • Page 10: Disassembly And Assembly

    DISASSEMBLY AND ASSEMBLY Cautions to be observed when troubleshooting. Unlike many other appliances, the microwave oven is high-voltage, high-current equipment. It is completely safety during normal operation. However, carelessness in servicing the oven can result in an electric shock or possible danger from a short circuit. You are asked to observe the following precautions carefully.
  • Page 11 1. To remove cabinet 1) Remove thirteen screws on cabinet. 2) Pull the cabinet backward. 2. To remove control panel assembly 1) Remove three screws which secure the front plate. 2) Remove the control panel assembly from front plate of cavity.
  • Page 12 4. To remove control panel parts. C/PANEL ASSEMBLY : PKCPSWZYD0 REF. NO PART CODE PART NAME DESCRIPTION Q'TY REMARK 3516742100 CONTROL-PANEL ABS SG-175, SG-0760D 3514333500 PCB SUB AS KOM-9F0CTS 7122401211 SCREW TAPPING T2S TRS 4*12 MFZN 1) Remove three screw which secure the control panel, push up two snap fits and draw forward the control panel assembly.
  • Page 13 REF. NO PART CODE PART NAME DESCRIPTION Q'TY REMARK 3512211600 FRAME DOOR ABS SG-175, SG-0760D 3511732410 DOOR SEAL AS KOM-9F2CTS 7122400811 SCREW TAPPING T2S TRS 4*8 MFZN 3512303300 GASKET DOOR PP GP2300 3512604340 HANDLE DOOR 7122401211 SCREW TAPPING T2S TRS 4*12 MFZN...
  • Page 14 6. Method to reduce the gap between the door seal and the oven front surface. (1) To reduce gap located on part ‘A’ • Loosen screws on top of lock and then, close the door with adjusting gap of front surface of oven. •...
  • Page 15 NOTE : Never install the magnetron without the metallic gasket plate which is packed with each magnetron to prevent microwave leakage. Whenever repair work is carried out on magnetron, check the microwave leakage. It shall not exceed 4mW/cm for a fully assembled oven with door normally closed. Magnetron antenna Wave guide Magnetron antenna Metalic...
  • Page 16 10. To remove H.V.transformer. 1) Remove each four screws holding the H.V. transformer. 2) Remove the H.V.transformer. 3) Reverse the above steps for reassembly. 11. To remove lamp. 1) Remove one screws holding the cover lamp. 2) Remove counterclockwise direction lamp from the bracket lamp.
  • Page 17 13. To remove motor syncro. 1) Push left side of stopper in centre of cover stirrer and seperate it from cavity. 2) Hold side stoppers of cover stirrer with both hands and pull down. Then take off the cover stirrer out of the oven cavity 3) Remove three fixture supporter stirrer holding the stirrer *t.

  • Page 18: Interlock Mechanism And Adjustment

    INTERLOCK MECHANISM AND ADJUSTMENT The door lock mechanism is a device which has been specially designed to completely eliminate microwave radiation when the door is opened during operation, and thus to perfectly prevent the danger resulting from the leakage of microwave. PRIMARY INTERLOCK SWITCH LEVER LOCK *T...

  • Page 19: Troubleshooting Guide

    TROUBLESHOOTING GUIDE Following the procedure below to check if the oven is defective or not. 1) Check earthing before trouble checking. 2) Be careful of the high voltage circuit. 3) Discharge the high voltage capacitor. 4) When checking the continuity of the switches, fuse or high voltage transformer, disconnect one load wire from these parts and check continuity with the AC plug removed.
  • Page 20 CONDITION CHECK RESULT CAUSE REMEDY Replace Defective Outlet has Check continuity of magnetron Continuity magnetron proper voltage Fuse does not Replace blow. Open power Check continuity of Continuity supply cord power supply cord Adjust Normal Defective touch control circuit Replace Malfunction of Display do not show secondary...
  • Page 21 CONDITION CHECK RESULT CAUSE REMEDY Check continuity of primary Adjust or Malfunction of Continuity interlock switch replace Fan motor primary interlock does not switch rotate Check continuity of secondary Adjust or Malfunction of Continuity interlock switch replace secondary interlock switch Replace Check D.C.
  • Page 22 (TROUBLE 3) No microwave oscillation even though fan motor rotates. CONDITION CHECK RESULT CAUSE REMEDY Continuity Replace Check continuity if high Defective high microwave voltage capacitor terminals voltage oscillation with wires removed transformer Continuity in Replace Check continuity of high voltage Defective high backward rectifier in forward and backward...
  • Page 23 (TROUBLE 4) The following visual conditions indicate a probable defective touch control circuit or membrane switch assembly 1. Incomplete segments, 1) Segments missing. 2) Partial segments missing. 3) Digit flickering other than normal display slight flickering. 2. The display does not show the contents correctly when you touch a pad.

  • Page 24: Measurement And Test

    MEASUREMENT AND TEST 1. MEASUREMENT OF THE MICROWAVE POWER OUTPUT Microwave output power can be checked by indirectly measuring the temperature rise of a certain amount of water exposed to the microwave as directed below. PROCEDURE 1. Microwave power output measurement is made with the microwave oven supplied at rated voltage and operated at its maximum microwave power setting with a load of 1000±5cc of potable water.

  • Page 25: Microwave Radiation Test

    2. MICROWAVE RADIATION TEST CAUTION : 1. Make sure to check the microwave leakage before and after repair of adjustment. 2. Always start measuring of an unknown field to assure safety for operating personnel from microwave energy. 3. Do not place your hands into any suspected microwave radiation field unless the safe density level is known. 4.

  • Page 26: Component Test Procedure

    1. High voltage transformer (1) Remove connections from the transformer terminals and check continuity. (2) Normal readings should be as follows : Secondary winding..Approx. 100Ω ± 10% (110Ω ± 10% : KOM-9F2CTS Filament winding................Approx. 0Ω Primary winding ...............Approx. 15Ω 2. High voltage capacitor (1) Check continuity of capacitor with meter on the highest OHM scale.

  • Page 27: Wiring Diagram

    WIRING DIAGRAM...
  • Page 28 NOTE : When replacing, check the lead wire color as shown. Colors shown by ( ) indicate colors of lead wire connector housing. (FRONT SIDE) Low Voltage IC MICOM Transformer (RD/RD) (RD/BK) (RD/RD) (RD/BK) (WH) (BL) MAGNETRON(Bottom) MAGNETRON(Top) HV CAPACITOR(Top) HV CAPACITOR(Bottom) (WH)Top (WH)Top...

  • Page 29: Printed Circuit Board

    PRINTED CIRCUIT BOARD 1. CIRCUIT CHECK PROCEDURE 1. Low voltage transformer check The low voltage transformer is located on the P.C.B. Measuring condition: Input voltage: 240V / Frequency: 50Hz Terminal Voltage LOAD NO LOAD 6-7, 7-8 DC 12V AC 25.8V 9-10 AC 2.5V AC 3.0V...
  • Page 31 3. When there is no microwave oscillation Cause : RELAY 1 or RELAY 4 does not operate. POINT STATE RELAY 1 ON 5VDC RELAY 1 OFF 12VDC RELAY 4 ON 5VDC RELAY 4 OFF 12VDC 2) When touching START pad, oven lamp or fan motor does not turn on but cook indicator in display comes on. - Oven lamp does not turn on Cause : RELAY 8 does not operate.
  • Page 32 4. When the door is opened during operation the countdown timer does not stop. POINT STATE DOOR OPEN 5VDC OPEN DOOR CLOSED CLOSE CHECK NO METHOD REMEDY Check the state(ON, OFF) of the door open Replace door open monitor switch monitor switch by resistance measurement.
  • Page 33 7. Initializing Service Information To initialize the oven usage history, press and hold 3 pad for 3 seconds when the door is opened. The display will show “SERVICE” message, then you can select the service information to be initialized by pressing a number pad as described below.

  • Page 34: Circuit Diagram

    2. P.C.B. CIRCUIT DIAGRAM...

  • Page 35: P.c.b.location No

    Caution In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). 3. P.C.B.LOCATION NO. NAME SYMBOL PART CODE...

  • Page 36: Exploded View And Parts List

    EXPLODED VIEW AND PARTS LIST 1. DOOR ASSEMBLY Refer to Disassembly and assembly. 2. CONTROL PANEL ASSEMBLY Refer to Disassembly and assembly. 3. TOTAL ASSEMBLY F01 F02 F03 F04 F05 F06 F07 F10 F25 F26 F27 F70 F68...
  • Page 37 So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). REF. NO PART CODE PART NAME DESCRIPTION Q'TY REMARK 3511732400 DOOR AS KOM-9F2CTS PKCPSWZYD0 CONTROL-PANEL AS KOM-9F2CTS 3516122300 CAVITY AS KOM-9F0CTS 3517318390 FOAM PU 35TX15X50 U-L...
  • Page 38 So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). REF. NO PART CODE PART NAME DESCRIPTION Q'TY REMARK 3518704500 FUSE HV 5KV 800MA *THV-060T HD-CMO KOM-9F2CTS(1850W) 3518704510 FUSE HV 5KV 700MA *THV-060T HD-CMO KOM-9F2CKS(1500W) 3518003810 MAGNETRON 2M248H(DW)-B 7S627W50X1 NUT HEX NUT FLANGE M5X0.8P MFZN...
  • Page 39 DAEWOO ELECTRONICS CORP. 1-2, Jeo-dong 1(il)-ga, Jung-gu, Seoul, Korea C.P.O. BOX 8003 SEOUL, KOREA TELEX: DWELEC K28177-8 CABLE: “DAEWOOELEC” S/M NO. : PRINTED DATE: May. 2012...
  • Page 40 ABOUT THIS MANUAL ABOUT THIS MANUAL ! ! " " # # " " $ $ % % & & ' ' ( ( ) ) * * + + " " ! ! ) ) , , & & " " % % ' ' - - ./ 012 345 678 9:;<...
