  • Page 1 ABOUT THIS MANUAL ABOUT THIS MANUAL...
  • Page 2 MICROWA VE OVEN KOR-6N4R OPERATING INSTRUCTIONS Before operating this oven, please read these instructions completely.

  • Page 3: Table Of Contents

    PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.

  • Page 4: Earthing Instructions

    EARTHING INSTRUCTIONS This appliance must be earthed. In the event of an electrical short circuit, earthing reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a earthing wire with a earthing plug.

  • Page 5: Specifications

    SPECIFICATIONS POWER SUPPLY 230V AC 50 Hz SINGLE PHASE WITH EARTHING POWER CONSUMPTION 1200 W MICROWAVE OUTPUT POWER 800 W FREQUENCY 2450 MHz OUTSIDE DIMENSIONS (W X H X D) 465 X 279 X 356 mm CAVITY DIMENSIONS (W X H X D) 301 X 230 X 283 mm NET WEIGHT APPROX.

  • Page 6: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING : To prevent fire, burns, electric shock and other warnings: Listed below are, as with all appliances, certain rules to follow and safeguards to assure high performance from this oven: 1.

  • Page 7: Features Diagram

    FEATURES DIAGRAM 1 Door latch - When the door is closed it will 6 Control Panel automatically shut off. If the door is opened 7 Glass cooking tray - Made of special heat while the oven is operating, the magnetron will automatically shut off.
  • Page 8 FEATURES DIAGRAM ( continued ) Power Defrost Clock Auto Cook 1. Dinner Plate 2. Soup 3. Beverage 4. Fresh Vegetable Stop/Clear Start/Easy Cook 0 Display - Cooking time, Power level, indicators t Dial knob - Used to set time and weight. and present time are displayed.

  • Page 9: Operation Procedure

    OPERATION PROCEDURE This section includes useful information about oven operation. 1. Plug power supply cord into a 230V 50Hz power outlet. 2. After placing the food in a suitable container, open the oven door and put it on the glass tray. The glass tray and roller guide must always be in place during cooking.

  • Page 10: Controls

    CONTROLS SETTING THE CLOCK When the oven is first plugged in, the display will flash “ :0” and a tone will sound. If the AC power ever turns off, the display shows “ :0” when the power comes back on. 1.

  • Page 11: Time Defrosting

    TIME DEFROSTING When TIME DEFROST is selected, the automatic cycle divides the defrosting time into periods of alternating defrost and stand times by cycling on and off. 1. Press Defrost button. The DEF. indicator & “0” appear and the g Defrost indicator starts blinking.

  • Page 12: Cooking In One Stage

    COOKING IN ONE STAGE 1. Press Power button. The M/W indicator appears and the display will (Select the desired power show what you selected. Power level.) This example shows power level 6. NOTE: If step 1 is omitted, the oven will cook at full power.

  • Page 13: Easy Cook

    EASY COOK EASY COOK allows you to reheat for 30 seconds at 100% (full power) by simply pressing the Easy cook button. By repeatedly pressing the Easy cook button, you can also extend reheating time to 5 minutes by 30 seconds.

  • Page 14: Child Safety Lock

    CHILD SAFETY LOCK SAFETY LOCK lock prevents unwanted oven operation such as by small children. To set, press and hold Stop/Clear button for 3 seconds, Lock indicator appears and a beep sounds. To cancel, press and hold Stop/Clear button for 3 seconds, Lock indicator disappears and a beep sounds. TO STOP THE OVEN WHILE THE OVEN IS OPERATING 1.

  • Page 15: Cooking Utensils

    COOKING UTENSILS Only use utensils that are suitable for use in microwave ovens. Microwave energy is produced by high frequency radio waves. They are reflected from metal, but will pass through most cooking utensils without heating them. As the waves come into contact with the food, they are converted into heat energy. Listed below are the suggested cooking utensils for this microwave oven and when to use them.

  • Page 16: Before You Call For Service

    BEFORE YOU CALL FOR SERVICE Refer to the following checklist, you may prevent an unnecessary service call. * The oven doesn't work; 1. Check that the power cord is securely plugged in. 2. Check that the door is firmly closed. 3.
  • Page 17 Disposal of Used Electrical & Electronic Equipment The meaning of the symbol on the product, its accessory or packaging indicates that this product shall not be treated as household waste. Please, dispose of this equipment at your applicable collection point for the recycling of electrical & electronic equipments waste. In the European Union and Other European countries which there are separate collection systems for used electrical and electronic product.
