5. Installation & Connection
• Ensure the mains supply is switched off and the circuit supply fuses
are removed or the circuit breaker turned off.
• An isolating switch should be installed to enable the power to be
switched ON & OFF for maintenance purposes and to activate the
manual/auto override function.
• Remove the wiring cover from the sensor by depressing the catch
on the side and lifting it clear of the twin locators opposite the
catch (See diagram "G").
• Mark the position of the 75mm diameter fixing hole centre taking care
to avoid ceiling joists and other obstructions within the 75mm diameter.
• Using a pad saw or suitable hole cutter cut out a 75mm diameter hole
• Pass the 230V 50Hz mains supply and load cables through the hole
and prepare for termination.
• Terminate the cables into the terminal block ensuring correct polarity
is observed and that all bare conductors are sleeved (See below details
3
on connection);
THERE ARE 2 POSSIBLE CONNECTION SCENARIOS
Standard connection – 230v Mains Installation
(see diagram "E")
The factory fitted 'bridge' wire must not be removed.
Connect the 3 or 4 core mains supply cable to the block on the unit
as follows:-
NEUTRAL (Blue)
EARTH (Green/Yellow)
LIVE (Brown)
Connect the fourth core (lighting live) of the four core cable (if used)
to the L
to L
1
terminal block or the second 3 core cable (from the lighting)
1
(brown), N (blue) and E (green/yellow).
N
L
