ESAB FABRICATOR 141i

9.03 Hardware List

ITEM
1 Nut Lock, M20
2 Screw Hexagon, M10 × 1.5-20 ST ZP
3 Washer, M4, ET Lock
4 SC PHCR M4 × 0.7-10 ST ZP
5 SC PHCR M4 × 0.7-16 ST BK
6 SC PHCR ST 6G × 3/8 STBK
7 Nut Hexagon M4 × 0.7 ST ZP
8 SC PHSL M4 × 0.7-30 ST ZP
9 Nut Hexagon M12 × 1.75 ST ZP
10 Washer Flat, 7.91 D (M8)
11 Washer Spring, 7.91 D
12 Screw Hexagon M8 × 1.25-30 ST ZP
13 Nut Hexagon M8 × 1.25 ST ZP
14 Screw Hexagon HD 9/32 × 16 ×19
15 Screw Skt Set M4 × 0.7
16 Screw Hexagon M6 × 1.0-10 ST ZP
17 Nut Hexagon M10 × 1. 5 ST ZP
NOTE!
All the hardware can be purchased from local store.
KEY SPARE PARTS
DESCRIPTION Torque
≥ 50 kgfcm 25mm Dinse
≥ 50 kgfcm 25mm Dinse
15 ± 1 kgfcm Handle
Side Panel
15 ± 1 kgfcm Handle
Rear Panel
Front Panel
Side Panel
Door Assy
15 ± 1 kgfcm Front Panel
Rear Moulding
10 ± 1 kgfcm 8 Pin Remote Socket
Front PCB
15 ± 1 kgfcm Fan
15 ± 1 kgfcm Fan
≥ 50 kgfcm Gas Adaptor Inlet
≥ 50 kgfcm Wirefeeder Plate
N/A Wirefeeder Plate
≥ 50 kgfcm Wirefeeder Plate
≥ 50 kgfcm Wirefeeder Plate
48 ± 1 kgfcm Wirefeeder Plate
15 ± 1 kgfcm ESAB No. 4 Torch Adaptor
48 ± 1 kgfcm ESAB No. 4 Torch Adaptor
≥ 50 kgfcm ESAB No. 4 Torch Adaptor
Table 9-3
9-4
WHERE USED
2
2
2
3
2
2
3
3
2
2
2
2
4
4
4
1
2
2
2
2
2
1
1
1
Manual 0-5448
Qty
