  • Page 1 Cine-W Owner’s Manual Wall mount Stage y (hanging) mount T-stand • TO THE OWNER • INSTALLATION INSTRUCTIONS • OPERATING THE SCREEN • MAINTENANCE CW-0814 TO THE INSTALLER : BE SURE TO LEAVE THIS MANUAL WITH TH E OWNER.
  • Page 2 Printed in U.S.A. ©2008–2014 Stewart Filmscreen Corporation Stewart Filmscreen reserves the right to make changes to the product speci ed in this document. From time to time, this document is updated. Current versions of documentation are posted on the Stewart Filmscreen website at: www.stewart lmscreen.com...

  • Page 3: Table Of Contents

    Screen Care and Cleaning ......12 Product Warranty ....... . . 13 Cine-W: Owner’s Manual...

  • Page 4: To The Owner

    (hanging) mounts. Using this manual for installation If you are using this manual to inst all the Cine-W, you should be aware that it describes procedures for several types of mounts. You must refer to the section for the type of screen mount.

  • Page 5: Wall Mount

    1. Connect the frame members by matching the colored, numbered dots on the ends of the frame pieces. Refer to Figure 1. 2. Secure frame members with the supplied 5/8” hex head bolts. Figure 1: Assembling the frame Cine-W: Owner’s Manual...
  • Page 6 3. During shipping, the frame brackets are attached to the wall mount brackets. Detach the frame brackets from the wall mount bracket and attach them to the frame using two 1/4-20 Allen head machine screws per bracket. See Figure 2. 4.
  • Page 7 Hanging the frame and screen on the wall 1. Go to the section “Attaching the Screen to the Frame” and attach the screen. 2. Attach the frame, with the screen att ached, to the previously mounted wall brackets using the 5/8” hex head bolts. Cine-W: Owner’s Manual...

  • Page 8: Stage Fly (Hanging) Mount

    TAGE ANGING OUNT Professional mounting techniques should be used. Stewart Filmscreen Corporation cannot be liable for substandard or faulty installations. As an alternative to the wall mount, you can use the stage fly mount to suspend the screen. 1. Assemble the frame. Refer to the section “Assembling the Frame”...

  • Page 9: T-Stand

    Corporation cannot be liable for substandard or faulty installations. Assembling the frame and attaching T-stands This sections describes how to mount the Cine-W on T-stands. 1. Connect the frame members by matching the colored, numbered dots on the ends of the frame pieces. Refer to Figure 1.

  • Page 10: Attaching The Screen To The Frame

    TTACHING THE CREEN TO THE RAME This section provides the instructions for att aching the screen to the frame. DO NOT perform this step UNTIL instructed to do so in the section for the specific type of mount you are using. Caution ...
  • Page 11 Figure 6: Attaching the screen Cine-W: Owner’s Manual...
  • Page 12 5. Attach the screen to the sides of the frame, att aching every other S-hook from the top to the center. If the screen edge is more than 1 to 2” (2.5 to 5 cm) from the frame on the right side, allow a few minutes for the screen to stretch before continuing.

  • Page 13: Troubleshooting

    Brush o or use a mild detergent s creen surface solution with clean rag or cotton swab. Perimeter or corner wrinkling Screen not properly centered Readjust screen mounting as required. onto frame Check all center attachment points. Cine-W: Owner’s Manual...

  • Page 14: Screen Care And Cleaning

    CREEN ARE AND LEANING With reasonable care, you may expect many years of trouble-free use of your Stewart projection screen. General maintenance The surface of your screen is delicate. Special attention to these instructions should be followed when cleaning. A draftsman-style brush may be used to lightly whisk away any ...

  • Page 15: Product Warranty

    Stewart Filmscreen Corporation shall not be liable for any and all consequential damage(s) occasioned by the breach of any written or implied warranty pertaining to the sale in excess of the purchase price of the product sold. Printed in USA. Rev. 12/14/10 Cine-W: Owner’s Manual...
  • Page 16 800.762.4999 310.784.5300 Fax: 310.326.6870 • • January 2014 Printed in U.S.A. www.stewartfilmscreen.com ©2008–2014 Stewart Filmscreen Corporation...
