  • Page 1 Luxus A / SR-1 Electriscreen O W N E R ’ S M A N U A L To the Owner Installation Instructions Operating the Screen Maintenance LXSR-0903 O T H E I N S T A L L E R E S U R E T O L E A V E T H I S M A N U A L W I T H T H E O W N E R...
  • Page 2 Printed in U.S.A. ©2003 Stewart Filmscreen Corporation.

  • Page 3: Table Of Contents

    Luxus A / SR-1 Electriscreen O W N E R ’ S M A N U A L Contents To The Owner ........2 Preparing The Installation .

  • Page 4: To The Owner

    WNER Congratulations on your purchase of the finest optical viewing screen available anywhere in the world! Please take a moment to review this manual, it will help ensure you many years of trouble-free service from your new Stewart Filmscreen product. About your Luxus A Series Electriscreen This is Stewart’s most popular electric roll up unit because it can accommodate screen sizes up to 66”...
  • Page 5 Luxus A/SR-1 Electriscreen: Owner’s Manual HDTV Format (16:9/1.78:1 Aspect Ratio Luxus A Luxus SR- Image Model # 1 Model # Diagonal LX082H- SR082H- 82” LX092H- SR092H- 92” LX100H- SR100H- 100” LX110H- SR110H- 110” LX123H- SR123H- 123” LX135H- 135” Wide Screen Format (1.85:1 Aspect Ratio) Luxus A Luxus SR- Image...

  • Page 6: Preparing The Installation

    REPARING NSTALLATION Before proceeding with the installation of this screen, be sure to read and understand all the installation and operating instructions thoroughly. All electrical wiring installations must conform to local and national codes and should be performed by qualified service personnel. There are no user-serviceable parts contained within the unit.
  • Page 7 Luxus A/SR-1 Electriscreen: Owner’s Manual Unpacking Warning! Failure to remove the batten lock-down screws can result in permanent damage to the screen. 1. Remove the outer plastic covering and white wrapping paper surrounding the screen case. 2. Do not remove the wrapping paper surrounding the screen roller. You should remove it only after the unit is hung and all electrical connections have been made.

  • Page 8: Step 1. Hanging The Case

    1. H ANGING Figure 2: Wall mount using optional brackets Electrical Connection Box (behind end plate) Socket Screws Electrical Knockout (optional) Figure 3: Ceiling or top mount Professional mounting techniques should be adhered to. Stewart Filmscreen Corporation cannot be liable for substandard or faulty installations.

  • Page 9: Suspended Installation

    Support Structure Drywall or suspended ceiling Figure 4: Recessed or concealed mount Figure 5: Suspended installation Luxus A/SR-1 Electriscreen: Owner’s Manual Recessed or concealed mount You can install the screen so that the motor is recessed and the bottom is flush with dry wall or a suspended ceiling.

  • Page 10: Step 2. Electrical Hook-Up

    2. E LECTRICAL Electrical Connection Box (behind end plate) Socket Screws Electrical Knockout (optional) Figure 6: Electrical connection Caution Professional techniques need to be adhered to when making any electrical connection. A qualified electrician should perform these procedures. Be sure to follow all standard safety procedures for installing electrical devices.

  • Page 11: Preparing The Connection

    DOWN-Black UP-Red Line (Hot) COMMON-White Neutral GROUND-Green Figure 7: High voltage control wiring diagram Luxus A/SR-1 Electriscreen: Owner’s Manual Installing the high voltage switch control (standard) A standard 3-position 120V wall switch is supplied. The high-voltage control is connected to the electrical source. It alternates directions of screen motion by means of the hot lead, using the 3-position switch.

  • Page 12: Making The Connection

    Optional 12V DC Transformer With Switch Figure 8: Screen trigger interface connection Installing the screen trigger interface option The optional 12V screen trigger interface enables up and down operation of the screen in conjunction with a projector, tuner, VCR, cable box, or switched AC outlet.
  • Page 13 120V AC Line Neutral COMMON-White UP-Red DOWN-Black Low Voltage Control Box Figure 9: Low voltage 3-button switch wiring Luxus A/SR-1 Electriscreen: Owner’s Manual Installing the low-voltage 3-button switch option The optional Stewart Filmscreen low-voltage control allows the use of low- voltage wire to connect to the supplied 3-position 24V momentary wall switch.
  • Page 14 Figure 10: Wireless remote control connection Installing the wireless remote control option The optional Stewart Filmscreen wireless remote control allows control of the screens from anywhere in the room. Once the AC power outlet is installed near the screen, an electrician is not needed to connect the wireless remote receiver module to the power source.
  • Page 15 120V AC Line Neutral COMMON-White UP-Red DOWN-Black Low Voltage Control Box Figure 11: Infrared remote control wiring Luxus A/SR-1 Electriscreen: Owner’s Manual Installing the infrared remote control option The optional Stewart Filmscreen infrared remote control allows control of the screens from anywhere in the room. Note: The distance between the hand-held remote control and the receiver can be up to 50 feet.

  • Page 16: Adjusting The Screen Extension

    PERATING CREEN DJUSTING CREEN The method you use to raise and lower the screen depends on the type of switch control devices you have selected. When you lower or retract the screen, it will stop at its preset limit. If an obstacle (such as a person or furniture) gets in the path of the screen as it is lowered, you should use the switch control to stop the screen's motion;...
  • Page 17 Down Limit Switch Limit Switch Screen Figure 12: Underside view of Luxus Luxus A/SR-1 Electriscreen: Owner’s Manual Modifying the extension of the screen You can increase the extension of the screen up to 3" past the factory preset stop, or you can decrease the extension by approximately 4-6" from the factory preset stop.

  • Page 18: Screen Care And Cleaning

    CREEN LEANING With reasonable care, you may expect many years of trouble-free use of your Stewart projection screen. We encourage you to keep your screen clean. To protect your screen when it is not in use, store it in the fully retracted position. Avoid getting any foreign material on the screen, as cleaning may prove very difficult.

  • Page 19: Troubleshooting

    ROUBLESHOOTING Problem description Screen won't operate. No 120V power available. Screen won't roll up or Bad connection at switch. down (even though power is available). Screen roller chatters Can be caused by voltage when power is activated. drop, bad connections, or a defective switch.
  • Page 20 www.stewartfilm.com 1-800-762-4999 Fax (310) 326-6870...
