Dimensions and Clearances

A. Appliance Dimensions
31-3/8
Figure 7.1 Front View
21-5/16
16-15/16
Figure 7.2 Side View
November 29, 2016
13-1/16
20-1/16
28-5/16
28
31-7/16
NOTE: Flue Collar size is 6 inch (152mm) diameter (ID)
3
8-3/16
Figure 7.2 Top View
Figure 7.4 Side View with horizontal flue
7060-228G
Explorer III Wood Stove
30 1/8
24-1/8
28-5/8
Center
of Flue
7
