Table Of Contents - Quadra-Fire EXPLR-III-PBK Installation Manual

Explorer III Wood Stove
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
•
• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE: Indicates practices which may cause damage to the appliance or to property.
Important Safety Information .............3
1
A. Appliance Certification ......................................................3
B. BTU & Efficiency Specifications........................................3
C. Mobile Home Approved (USA ONLY) ............................... 3
D. Glass Specifications .........................................................3
E. Non-Combustible Materials ..............................................3
F. Combustible Materials .......................................................3
Getting Started ....................................4
2
A. Design and Installation Considerations ............................4
B. Fire Safety ........................................................................4
C. Negative Pressure ............................................................5
D. Tools And Supplies Needed ..............................................5
E. Inspect Appliance and Components .................................5
F. Removal of Appliance from Shipping Materials .................5
F. Install Checklist .................................................................6
Dimensions and Clearances ..............7
3
A. Appliance Dimensions ......................................................7
B. Hearth Protection Requirements ......................................8
C. Clearances to Combustibles.............................................9
D. Locating Your Appliance & Chimney.................................10
E. Chimney Termination Requirements .................................10
F. 2-10-3 Rule .......................................................................11
Quadra-Fire is a registered trademark of Hearth & Home Technologies.
2

TABLE OF CONTENTS

Chimney Systems .............................12
4
A. Venting Components .......................................................12
B. Chimney Systems .............................................................12
C. Installing Chimney Components .......................................14
Appliance Set-Up ..............................15
5
A. Outside Air Kit Installation ................................................15
B. Installing Griddle Handle Storage Bracket .......................16
C. Blower (Optional) ..............................................................16
D. Optional Fire screen .........................................................16
E. Reversible Flue Collar and Horizontal Flue Heat Shield...17
Mobile Home Installation ..................18
6
Accessory List ..................................19
7
7060-228G November 29, 2016
