MODEL 800 NOVA FREESTANDING PELLET STOVE
INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS
CONGRATULATIONS—You are now the proud owner of one of the finest stoves in the world for your home—the QUADRA-
FIRE! Now before installing your stove and building your first fire, record the serial number on the warranty card. The serial
number is located on the safety label on the back wall of the hopper.
PLEASE READ ALL OF THE OWNERS MANUAL AND SAFETY NOTES
1.
When installing your stove, particular attention should be paid to fire protection. If this unit is not properly installed, a house
fire may result. For your safety, follow the installation instructions, and contact local building or fire officials about restrictions
and installation inspection required in your area.
2.
Read power supply section of component information (page 16) before you plug in the stove.
3.
Always unplug the stove before cleaning or servicing.
4.
Do not connect the stove to a chimney flue already serving another appliance.
5.
The stove operates with a negative pressure firebox and a positive pressure exhaust. It is imperative that the chimney system
be airtight and installed correctly.
6.
Dispose of all ashes in a metal container.
7.
Comply with all minimum clearances to combustibles as shown on page 5.
8.
The Quadra-Fire 800 NOVA is tested and approved for pelleted biomass fuel only. Burning of any other type of fuel voids your
warranty!
9.
Aladdin Hearth Products, manufacturer of the 800 NOVA pellet stove, reserves the right to alter its products, their specifications
and/or price without notice.
ALADDIN HEARTH PRODUCTS, GRANTS NO WARRANTY, IMPLIED OR STATED, FOR THE INSTALLATION OR
MAINTENANCE OF THIS UNIT AND ASSUMES NO RESPONSIBILITY FOR ANY CONSEQUENTIAL DAMAGE(S).
401 N. Wynne Street
Colville, WA 99114
N o r t h A m e r i c a ' s B e s t
IMPORTANT SAFETY NOTES
Part #250-2230 #812-2520
SAVE THESE INSTRUCTIONS
Revised 3/98
www.quadrafire.com
aladdin@plix.com
Advertisement
Table of Contents
Related Manuals for Quadra-Fire 800 NOVA
Summary of Contents for Quadra-Fire 800 NOVA
- Page 1 Dispose of all ashes in a metal container. Comply with all minimum clearances to combustibles as shown on page 5. The Quadra-Fire 800 NOVA is tested and approved for pelleted biomass fuel only. Burning of any other type of fuel voids your warranty! Aladdin Hearth Products, manufacturer of the 800 NOVA pellet stove, reserves the right to alter its products, their specifications and/or price without notice.
- Page 2 NOTES Page 2...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Page Safety Label ................................4 Listing and Specifications ............................5 Installation ................................5 Clearances to Combustibles ............................. 5 Chimney and Exhaust Connections .......................... 5 Floor Protection ................................ 6 Venting Termination Requirements .......................... 6 Venting Systems ............................... 7 A. -
Page 4: Safety Label
SAFETY LABEL (FOUND ON BACK WALL OF HOPPER) Page 4... -
Page 5: Listing And Specifications
LISTINGS AND SPECIFICATIONS QUADRA-FIRE 800 NOVA pellet stoves are safety tested and listed with Warnock Hersey International to ASTME 1509 and ULCS627. Also suitable for mobile home installation (see page 11 for details). HEAT INPUT*: 28,000 to 37,500 BTU per hour PARTICULATE EMISSIONS PER HOUR: 0.9 grams per hour... -
Page 6: Floor Protection
FLOOR PROTECTION MINIMUM CLEARANCES TO COMBUSTIBLE MATERIALS The floor protector must be noncombustible material, extending beneath heater and to the front, sides, and rear as indicated below. G = 2" (50mm) H = 6" (150mm) NOTE: In a corner installation, the floor protection must follow the above clearances. VENTING TERMINATION REQUIREMENTS Do not terminate vent in any enclosed or semi-enclosed area such as a carport, garage, attic, crawl space, under a sun deck or porch, narrow walkway or closely fenced area, or any location that can build up a concentration of fumes such... -
Page 7: Venting Systems
Page 7... -
Page 8: Through The Wall And Vertical
Page 8... -
Page 9: Venting Graph
Page 9... -
Page 10: Vertical
TOP VENT FLUE ADAPTER INSTALLATION INSTRUCTIONS 3"-3" ADAPTER #811-0450 3"-6" COLLAR #812-2690 Put a layer of silicone on the 3" (76mm) exhaust outlet. Slide the flue adapter onto the rear exhaust outlet. Adjust the assembly to a vertical position. Slide the outer shield up or down to mate evenly with the top of stove. -
Page 11: Mobile Home Installation
MOBILE HOME INSTALLATION OUTSIDE AIR KIT FOR 800 NOVA: PART #811-0420 (FLOOR) OR PART #811-0430 (REAR) An outside air inlet must be provided for the combustion air and be unrestricted while the stove is in use. The stove must be secured to the mobile home by bolting it to the floor (using lag bolts). -
Page 12: Operating Instructions
OPERATING INSTRUCTIONS 1. FUEL SIZE AND MATERIAL Fuel pellets are made from sawdust or wood byproducts. If the source material is hardwood, they will have a higher mineral content, creating a heavier ash. Minerals and other noncombustible materials, such as sand, will turn into glass when heated to the extreme temperatures our firepot reaches. -
Page 13: Schematic
Page 13... -
Page 14: Schematic Key And Electrical Schematic
COMBUSTION BLOWER WHITE Page 14... -
Page 15: Cleaning And Maintenance
CLEANING AND MAINTENANCE NOTE: Unplug the stove before performing any cleaning or maintenance 1. FIREPOT A. It takes very little time to clean the firepot. We recommend that you clean the firepot at least once a week. However, if the fuel you are burning has a high dirt content, it will be necessary to clean the firepot more often. -
Page 16: Component Information
COMPONENT INFORMATION 1. POWER SUPPLY 6. JUNCTION BOX AND WIRING HARNESS A. Check the wall receptacle for 120 volt, 60 Hz (standard A. The junction box and the wiring harness are located current). Make sure the outlet is grounded and has on the left side of the stove. - Page 17 9. THERMOCOUPLE B. The blower is accessible by removing the left rear (facing A. The thermocouple is located on top of the firepot inside the the stove from the front) pedestal access door. You ceramic protection tube. Remove the ceramic tube and should inspect this blower at least once a year.
-
Page 18: Troubleshooting
TROUBLESHOOTING NOTE: In order to identify the component location, refer to schematics on pages 13 and 14. CAUTION: UNPLUG STOVE BEFORE SERVICING 1. PLUG IN STOVE, NO RESPONSE 5. SLOW OR SMOKY START-UP A. Check the power supply for 120 volts AC. A. - Page 19 8. THERMOSTAT WILL NOT START UNIT 13. LARGE FIRE, ASH BUILDUP AND DIRTY A. Check the power to the stove. GLASS 1. Unplug for 10 seconds and then plug in. The A. Clean the firepot. Check the firepot gasket for a good exhaust blower should come on.
-
Page 20: Warranty
N o r t h A m e r i c a ’ s B e s t lifetime warranty Aladdin Hearth Products, warrants their pellet heating appliances to the original purchaser for the lifetime of the appliance, to be free from defects in material and workmanship.
