Summary of Contents for Blaupunkt IVOD-1002
-
Page 3: Table Of Contents
TABLE OF CONTENTS Overhead DVD System ... . . 3 Infrared remote control overview ..5 Notes for the user ....7 Precautionary measures . -
Page 4: Overhead Dvd System
OVERHEAD DVD SYSTEM Switch for interior lighting PLAY/PAUSE Play the disc, pause (freeze frame) Reset button (located on base) Source Select A/V source (DVD, AV1, Monitor auto power ON/OFF AV2) (located on base) AV 2 input selected DVD: next chapter; VCD/CD/MP3: next track menu: AV1 AV 1 input selected move cursor upwards... - Page 5 OVERHEAD DVD SYSTEM Headphone jack 1 DVD player disc slot Volume control for headphone jack 1 Volume control for headphone jack 2 10 inch TFT display Headphone jack 2...
-
Page 6: Infrared Remote Control Overview
INFRARED REMOTE CONTROL OVERVIEW... - Page 7 INFRARED REMOTE CONTROL OVERVIEW POWER Turn system power on / off REPEAT Selects repeat mode 0 - 9 Numeric key buttons SLOW Slow motion play (only for DVD) PLAY/PAUSE Fast forward / fast reverse STOP OK Confirms selection DVD: Next / previous chapter VCD/CD/MP3: Next / previous track DISP Display time information (during MENU mode: Cursor up/down...
-
Page 8: Notes For The User
NOTES FOR THE USER Thank you for choosing a Blaupunkt • Avoid using the monitor in environments product. We hope you enjoy using this new where it is subjected to dust, dirt or piece of equipment. Please read these moisture. -
Page 9: Supplied Parts
SUPPLIED PARTS 1 Overhead DVD System 1 Mounting Plate 1 Trim Ring 1 Remote Control 1 Power supply cable (5 m) with fuses 5 Rubber Caps 1 User Manual Mounting Hardware Technical data, design and supplied parts may vary slightly due to product updating... -
Page 10: Installing The Unit
INSTALLING THE UNIT Select a suitable location for Before starting work, disconnect the ground cable from the vehicle battery’s negative secure installation of the unit. terminal in order to prevent short circuits. • The unit must not distract the driver or Note - follow the vehicle manufacturer’s restrict the driver’s view. - Page 11 INSTALLATION Mounting Plate Self- Tapping Screws Trim Ring Dome Light Trigger Switch Rubber Caps...
-
Page 12: Connections
INSTALLATION Marking the installation area. Power supply connections 1. Carefully pry the two transparent covers Cable color Category Connection of the interior lights off the unit from the Yellow input +12v permanent positive outside using a screwdriver. This allows (must be rated for at least 3 access to the two front mounting screw amps) holes. -
Page 13: Initial Operation
INSTALLATION Interior lighting (white): Initial operation The IVOD1002 has two built-in lamps that 1. Reconnect the vehicle battery. can be connected to the interior lighting 2. Restore complete function to the system of the vehicle. Connect the white electrical system (clock, on-board lead to the interior lighting circuit. -
Page 14: General Information
GENERAL INFORMATION Confidential unpublished works. 1992-1997 Dolby Laboratories. All rights reserved. Disc formats Supported formats CAUTION: Any inappropriate use of The following 8cm and 12 cm discs are the device may expose the user to supported: visible/invisible laser rays which exceed the limits for Class 1 laser products. -
Page 15: Handling And Cleaning Dvds And Cds
GENERAL INFORMATION Handling and cleaning DVDs Disc cleaning and CDs Use a dry soft cloth to wipe the surface of a disc. If the disc is especially dirty, use a soft cloth slightly moistened with isopropyl (rubbing) alcohol. Never use solvents such as benzine, or conventional record cleaners as they may mar the surface of the disc. -
Page 16: Basic Operation
BASIC OPERATION Switching on/off TFT display To switch on the system: Opening the display - Switch on the ignition. - Press the unlocking button for the display and pull the screen carefully - Press the POWER button on the downward. system or the remote control. - Page 17 BASIC OPERATION Display settings User settings - Press the Monitor Setup button once or This function allows the display settings, several times to call up the display brightness, contrast, color, tint and settings. sharpness to be saved for a specific user and then subsequently restored.
- Page 18 BASIC OPERATION Video CDs with PBC (playback control) Repeating chapters/tracks Video CDs with PBC can be played with or - Press the REPEAT button once, or without a menu: more than once to select the REPEAT mode as follows: - Press the MENU button to select between playback with or without PBC.
-
Page 19: Time Displays
BASIC OPERATION Time displays Press DISP for the fourth time: Press the DISP button during playback to TITLE 02 / 05 CHAPTER 001 / 027 display different time information on the 01 : 14 : 39 screen of the disc that is playing. Example: DVD: - Press DISP once:... -
Page 20: Selecting Audio Language
BASIC OPERATION TITLE button Notes: The number of subtitle languages is dependent on the inserted DVD. Some If the DVD has multiple titles recorded, you discs only contain one subtitle language. If can select the preferred title from the title only one language is available on the disc, menu to start playback. -
Page 21: Advanced Operation
ADVANCED OPERATION Make sure that the MP3 files have a file Note: The folder cannot be selected in this format designation of .mp3. mode. Two different modes of MP3 playback are Repeat file/directory - REPEAT available: - Press the REPEAT button once or more - WITH MENU than once to select one of the following - NO MENU... -
Page 22: Jpeg Image Cds
ADVANCED OPERATION JPEG image CDs - In order to start the slide show with a particular image from the folder The DVD player supports the display of currently selected, enter the number JPEG images. which appears after the image in the Ensure that the JPEG images have a file navigation menu using the numeric key format designation .jpg. - Page 23 ADVANCED OPERATION Image overview (digest mode) - Press MENU. - Up to nine thumbnail JPEG images are displayed on the screen. - The images are assigned to the numeric key buttons on the remote control as follows: - You can select the next/previous nine thumbnail images in the current directory using the buttons.
-
Page 24: Settings
SETTINGS Setup Menu • NORMAL/LB (For 4:3 Viewing) Played back in letterbox style. (If Main page connected to a wide-screen video source, In STOP mode: black bands appear at top and bottom of the screen.) - Press the SETUP button. - The initial SETUP menu is displayed. - Page 25 SETTINGS Speaker set-up menu SUBTITLE - Select the initial subtitle language you DOWNMIX prefer. This is to select the Dolby AC3 5.1 DISC MENU Downmix mode for the analog output. - Select the initial disc menu language Audio set-up menu you prefer.
-
Page 26: Maintenance And Care
Replacing the remote control batteries. Open the battery compartment on the back of the remote control. Remove the discharged batteries. Insert two AAA Alkaline batteries. Note the correct polarity (marked inside the battery compartment). Close the battery compartment. Changing bulbs Carefully pry the transparent cover of the interior lights off the unit using a small screwdriver. -
Page 27: Troubleshooting
TROUBLESHOOTING In rare cases, your DVD system may not function the way you expect it to. Before calling for service please read the operating instructions and go through the following check list. Symptoms Possible cause / remedy Player does not work when Check fuses (unit and vehicle) and connections switching on ignition and (see mounting instructions). -
Page 28: Glossary
GLOSSARY Dolby Digital JPEG (Joint Photographic Expert Group) Dolby Laboratories audio compression JPEG images are bitmapped images that technology that allows up to 6 channels use a compression method in order to save (Right, Left, Center, Surround Right, memory space. Surround Left and Subwoofer) in one audio Macrovision stream (AC3). - Page 29 GLOSSARY • PG-13 (Parental Guidance 13): allowed for VFD (Vacuum Fluorescent Display) viewing by children over 13 with parental This DVD player is equipped with a multi- supervision color display with adjustable brightness. • R (Restricted): parental supervision or the TFT (Thin Film Transistor) accompaniment by an adult is mandatory A technology for manufacturing large, high...
-
Page 30: Specifications
SPECIFICATIONS Model IVMR-1002 Screen size (Diagonal): 10" Monitor Screen resolution: 800 (H) x 3 (RGB) x 480(V) Active area: 216.0 (H) x 129.6 (V) Signal system: Dual system NTSC/PAL Brightness: 300 cd/m2 Contrast ratio: 400:1(Typ.) Viewing angle: Left/right: 55/55 degrees Up/down: 35/50 degrees Video input level: 1.0 Vpp ±... -
Page 31: Limited Warranty
To obtain performance of this warranty, contact the nearest Blaupunkt authorized repair facility or our nearest office. A dated purchase receipt or other proof that the product is within the warranty period will be required in order to honor your claim.
