- Page 1 In Car Video IVMR-9002 IVMR-1042 Operating and installation instructions 7 607 003 586 7 607 003 587 http://www.blaupunkt.com...
-
Page 2: Device Overview
DEVICE OVERVIEW > <... -
Page 3: Ceiling-Mounted Monitor
Ceiling-mounted monitor 1 Lights on the main unit 2 Light switch ON 3 Monitor latch 4 Vehicle interior lighting switch 5 Loudspeaker 6 Infrared receiver for IR remote control IVRC-06 Infrared transmitter for IR head- phones IVHS-01 (accessory) 7 Control button Increase the monitor volume / navigate in the OSD menu 8 Control button... -
Page 4: Ir Remote Control
DEVICE OVERVIEW E F G IR remote control D POWER On/off button for the monitor. E TV/VIDEO Input selector: switch between AV1 and AUX. F VOL • arrow button Increase the volume for the se- lected monitor. VOL • arrow button Decrease the volume for the se- lected monitor. -
Page 5: Table Of Contents
Switching on the monitor ... 25 OSD menu ... 26 IR headphones IVHS-01 (accessory) ... 26 Changing the light bulb ... 27 Changing the battery in the remote control ... 27 Specifcations ... 28 IVMR-9002 ... 28 IVMR-1042 ... 29... -
Page 6: Notes For The User
NOTES FOR THE USER Thank you for choosing a Blaupunkt product. We hope you enjoy using this new piece of equipment. Please read these operating instruc- tions before using the equipment for the first time. The Blaupunkt editors are constantly... -
Page 7: Safety Notices
NOTES FOR THE USER Note We recommend that you allow a spe- cialist workshop to carry out the instal- lation. Safety notices Please observe the following safety notices during installation and whilst making the connections. - Disconnect the negative and posi- tive terminals of the battery. -
Page 8: Installing The Monitor
INSTALLING THE MONITOR Installing the monitor (mechanical) Select a suitable position for secure installation of the monitor: The device must not distract the driver or restrict the driver’s view. The ability to enter and get out of the vehicle must not be impeded. The device must not be installed in such a way that could prevent the other vehicle components from... -
Page 9: Cables
Cables > System cable Adapter cable (13 pin) Cable for the interior lighting Signal cable (3 pin) (monitor hous- ing) (13 pin) INSTALLING THE MONITOR Interior lighting connection (3 pin) = Operating voltage (+12 V) White = To the door switch Black = Earth To avoid discharging the battery, we... -
Page 10: Operation
OPERATION Controlling the interior lighting (monitor) There are two switches for the lights: 2 and interior lighting This button is used to switch the lights on/off. Interior lighting If activated, the lights only come on when the vehicle’s doors are opened. Opening the monitor Pull back the monitor release latch 3 to flip down the LCD display. -
Page 11: Adjusting The Position Of The Monitor
Adjusting the position of the monitor The monitor can be rotated by up to approx. 30° to the right and left from its central viewing position. Closing the monitor Turn the monitor back to its central viewing position and push it into its base unit so that it clips back into the releasing/locking mechanism. -
Page 12: Osd Menu
OPERATION OSD menu Operation Press the MENU button : on the display or the MENU button I on the remote control to open the OSD menu. Use the arrow buttons 7 / 8 or to select the options. After you press the MENU button : or I you can use the arrow buttons to change the settings. -
Page 13: Changing The Light Bulb
Changing the light bulb Detach the monitor from the ceiling plate (4 screws). Screws for securing the ceiling-mounted monitor Remove the 3 screws of the metal cover (see picture below). Take out the old bulb. Fit a new bulb (12 V, 3 W). Refit the monitor. -
Page 14: Specifcations
SPECIFICATIONS IVMR-9002 Screen size: Screen resolution: Active area: Signal system: Brightness: Contrast ratio: Viewing angle: Video input level: Audio input level: AUX input level: Carrier frequency for IR sensor: Operating voltage (direct current): Current consumption: Quiescent current consumption: Operating temperature: Storage temperature: Dimensions: Weight:... -
Page 15: Ivmr-1042
IVMR-1042 Screen size: Screen resolution: Active area: Signal system: Brightness: Contrast ratio: Viewing angle: Video input level: Audio input level: AUX input level: Carrier frequency for IR sensor: Operating voltage (direct current): Current consumption: Quiescent current consumption: Operating temperature: Storage temperature:... - Page 16 01-4010 7320 01-89583 8394 210 57 69 473 01-4598830 02-369 6464 40 2085 023-565 6331 66-817 157 01-2185 11111 916-467952 08-7501810 01-8471650 02-6130 0514 01-324 8756 022-8771260 0212-3460040 708-6817188 +604-6413 640 Blaupunkt GmbH CM/PSS2 - 8 622 403 936 WWW: http://www.blaupunkt.com...
