Instruction Manual

Connecting Computers to the Console

To connect a computer controlled by USB peripherals, use a 1-to-2 cable

(SVECONUSx) to connect from one of the PC Ports located on the rear

panel of the KVM switch to the USB and Video ports on the computer, as

shown below.

VGA Port

1-to-2

USB Port

cable

To connect a computer controlled by PS/2 peripherals, use a 1-to-3 cable

(SVECONx) to connect from one of the PC ports to the PS/2 keyboard

and mouse, as well as the video port of the computer.
