SpectraLink Butterfly Quick Manual

Spectralink Butterfly
Quick Guide
14212000 Version 7.0
Charge your handset 4 hours prior to first use
for best performance.

Installing/Replacing Batteries

• Remove the battery. Use a paper clip or
a wide screwdriver to open on top of the
handset.
• Lift off the battery cover.
• Tilt the battery and position it in the battery
compartment with the (+) terminal first.
Press the battery into place so that the (-)
terminal is also connected.
• Press the back cover in locked position.
When you hear a click the back cover is in
position.
Note: Use only Ni-MH recharble batteries.

Turning Handset On/Off

• To turn on the handset, press .
• To turn off the handset, press until the
question Turn off? appears in the display.
• Confirm with "Yes".
For more information about the handset, refer to the user guide available for download at www.spectralink.com

Making calls

Off Hook Dialling (Dial Directly)

• Press to get dial tone.
• Dial the extension or external number.

On Hook Dialling (Pre-Dial)

• Dial the extension or external number.
• Press to dial the number.

Speed Dial Calls

• Press and hold a key (0-9) for three sec-
onds, until the call is initiated.

Answering and Ending Calls

• To answer a call, press .
• To end calls, press .

Call List Calls

• Press (-) on the left side of navigation key
to enter Call list.
• Scroll to desired name or number and
press .

Call Missed Calls

• Press (+) on the right side of navigation key
to enter missed call list.
• Scroll to the desired name or number and
press .

Phone Book Calls

• Press to enter phonebook.
• Scroll to the desired name and press
to dial the number.
1
2 3
4
6
5
8
7
9
10
11
13
12
Display
1
Left Softkey
2
Right Softkey
3
Speakerphone On/Off
4
Call List/Volume Control
5
Missed Call List/Volume Control
6
Phone Book
7
Navigation Keys
8
On Hooks
9
Off Hooks
10
Silent Mode
11
Microphone
12
Keypad Locks
13
