4.2.4 Editing Alphanumeric Parameters

If an external keyboard is not available, the character selection field is automatically opened
for entering alphanumeric parameters. Two models of the alphanumeric editor are available.

4.2.4.1 Alphanumeric Editor Type 1:

The u or d arrow keys switch between the editing line and the character selection field.
U U
Entering the text
Select the parameter.
Data entry is automatically activated after the data entry field is opened. The cursor is now
located at the start of the previous entry in the editing line.
Using the d arrow key, place the cursor in the character selection field.
U
The cursor now marks the first letter of the editor.
Using the l and
U
you want to enter in the editing line.
Press either the ENTER key or the rotary knob.
The character will be added to the editing line.
Correcting the entry
Using the u arrow key, place the cursor in the editing line.
U
Using the l and
U
want to delete.
Press the BACK key.
The entry to the left of the cursor will be deleted.
Correcting the entry
Using the u key, place the cursor in the editing line.
U
Press one of the unit keys or the rotary knob.
The data entry field will close, and the new entry will be accepted by the instrument.
Cancelling the entry
Press the ESC key.
The data entry field will close, and the previous entry will be retained.
Quick Start Guide 1302.6163.62 - 04
r arrow keys or the rotary knob, place the cursor on the character that
U
r arrow keys or the rotary knob, place the cursor after the character you
U
Basic Operation
Setting Parameters
Entry (editing) line
