R&S esu Quick Start Manual page 167

R&S ESU
Manual Operation of the R&S ESU with XP Remote Desktop
Click the Support tab.
The current TCP/IP configuration will be displayed.
If Assigned by DHCP appears in the Address Type field, go to step 2 (Create a fixed IP
address...). Otherwise, simply note the IP address and go to step 3 (Enable the
R&S ESU...).
2. Create a fixed IP address for the TCP/IP protocol as described in the section
" Configuring Existing Network Protocols (TCP/IP Protocol)" on page 2.31
3. Enable the R&S ESU for operation with Remote Desktop
Press the Windows key or CTRL+ESC.
The Windows Start menu will open.
Quick Start Guide 1302.6163.62 - 04
To avoid problems, use a fixed IP address.
When a DHCP server is used, a new IP address is assigned each time
the instrument is restarted. This address must first be determined on
the instrument itself. Thus, using a DHCP server is not suitable for
remote operation of the R&S ESU.
LAN Interface
6.25
