Page 1: User Manual
H3C S5820X & S5800 Series Ethernet Switches Interface Cards User Manual Hangzhou H3C Technologies Co., Ltd. http://www.h3c.com Document version: 6PW106-20150306... - Page 2 Copyright © 2008-2015, Hangzhou H3C Technologies Co., Ltd. and its licensors All rights reserved No part of this manual may be reproduced or transmitted in any form or by any means without prior written consent of Hangzhou H3C Technologies Co., Ltd. Trademarks H3C,...
- Page 3 Environmental protection This product has been designed to comply with the environmental protection requirements. The storage, use, and disposal of this product must meet the applicable national laws and regulations.
-
Page 4: Obtaining Documentation
Obtaining documentation You can access the most up-to-date H3C product documentation on the World Wide Web at http://www.h3c.com. Click the links on the top navigation bar to obtain different categories of product documentation: [Technical Support & Documents > Technical Documents]—Provides hardware installation, software upgrading, and software feature configuration and maintenance documentation. -
Page 5: Table Of Contents
Contents Optional Interface Cards ········································································ 1 Introduction to Optional Interface Cards ········································· 1 LSW1SP4P0 ························································································ 3 Front panel ···················································································· 3 SFP+ port status LEDs ···································································· 4 LSW1SP2P0 ························································································ 5 Front panel ···················································································· 5 SFP+ port status LEDs ···································································· 5 LSW1GP16P0 ···················································································· 6 Front panel ····················································································... -
Page 6: Optional Interface Cards
Table 1 Optional interface card types Interface Applicable to Description card type Provides four 1/10 Gbps SFP+ • fiber ports (see LSW1SP4P0). Connects to another SFP/SFP+ • port through an inserted SFP/SFP+ transceiver module and a cable. For more information about optional... - Page 7 S5820X SFP+ transceiver module series overview SFP transceiver module overview. Allows device connection with • SFP+ cables provided by H3C. For more information about SFP+ cables, see SFP+ cable overview. Provides sixteen 100/1000 • Mbps SFP copper/fiber ports (see LSW1GP16P0).
-
Page 8: Lsw1Sp4P0
Mbps fiber Ethernet ports (see LSW1GT16P). NOTE: The optional interface cards described in this document are applicable to many H3C switch models. For the up-to-date information about the switch models supporting the optional interface cards, consult H3C marketing staff or technical support. LSW1SP4P0... -
Page 9: Sfp+ Port Status Leds
SFP+ port status LEDs Each SFP+ port on the LSW1SP4P0 front panel has its own LED, which indicates the port status, as shown in Figure Table 2 Description of SFP+ port status LEDs Status Meaning The port operates at the rate of 10 Gbps;... -
Page 10: Lsw1Sp2P0
LSW1SP2P0 Front panel Figure 2 LSW1SP2P0 front panel (1) SFP+ port (2) SFP+ port status LED SFP+ port status LEDs Each SFP+ port on the LSW1SP2P0 front panel has its own LED, which indicates the port status. See Table 2 for LEDs description. -
Page 11: Lsw1Gp16P0
LSW1GP16P0 Front panel Figure 3 LSW1GP16P0 front panel (1) 100/1000Base-X SFP port (2) 100/1000Base-X SFP port status LED 100/1000Base-X SFP port status LEDs Each SFP port on the LSW1GP16P0 front panel has its own LED, which indicates the port status, as shown in the following table. - Page 12 Table 3 Description of 100/1000Base-X SFP port status LEDs Status Meaning The port operates at the rate of Solid 1000 Mbps; the LED is fast green blinking when data is being sent and/or received on the port. The port operates at the rate of Solid 100 Mbps only;...
-
Page 13: Lsw1Gt16P
LSW1GT16P Front panel Figure 4 LSW1GT16P front panel (1) 10/100/1000Base-T auto-sensing Ethernet port (2) 10/100/1000Base-T auto-sensing Ethernet port LED 10/100/1000Base-T auto-sensing Ethernet port LEDs Each Ethernet port on the LSW1GT16P front panel has its own LED, which indicates the port status, as shown in the following table. - Page 14 Table 4 10/100/1000Base-T auto-sensing Ethernet port LEDs description Status Meaning The port operates at the rate of Solid 1000 Mbps; the LED is fast green blinking when data is being sent and/or received on the port. The port operates at the rate of Solid 10/100 Mbps;...
- Page 15 NOTE: By default, the port LED is in the rate mode. To change the rate mode to duplex mode, you can press the mode button. For more information about the mode button, see the installation manuals of different switch series.
-
Page 16: Installing And Removing An Optional Interface Card
Installing and Removing an Optional Interface Card NOTE: This section takes the LSW1SP4P0 interface card and the H3C • S5820X-28C switch to illustrate the module installation and removal. The installation tools are not shipped together with H3C’s • Ethernet switches. You need to prepare the tools. - Page 17 Figure 5 Remove a blank panel (1) Phillips screwdriver (2) Switch's front panel (3) Blank panel NOTE: Keep the removed blank panel properly for future use. Unpack the interface card.
- Page 18 Figure 6 Interface card appearance (1) Captive screw (2) Ejector lever Gently push the interface card in along the guide rails until the interface card is in close contact with the switch (see callout 1 Figure 7). Then push the ejector levers at both sides inward (see callout 2 in Figure Fasten the captive screws with a Philips screwdriver to fix the...
-
Page 19: Removing An Interface Card
Figure 7 Install an interface card Removing an Interface Card Put on an ESD-preventive wrist strap and make sure that the strap is in good contact with your skin and is properly grounded. Loosen the captive screws at both sides of the interface card using a Phillips screwdriver. - Page 20 NOTE: When installing or removing an optional interface card, pay attention to the following points: Avoid touching the surface-mounted components directly with • your hands. Avoid using excessive force in the operation. • After removing an interface card, if no module is to be installed, •...
-
Page 21: Ordering And Installing Transceiver Modules
For the most recent list of SFP transceiver modules, SFP+ transceiver modules, and SFP+ cables available for the interface cards, contact H3C Support or marketing staff. For more information about H3C SFP transceiver modules, SFP+ transceiver H3C Transceiver Modules User... -
Page 22: Sfp+ Cable Overview
SFP+ cable overview Figure 9 An SFP+ cable (1) Connector (2) Handle SFP+ cables support the SFP+ standard and use 10G SFP+ Cu standard cables. H3C provides the following types of SFP+ cables with various lengths, as shown in Table... - Page 23 3 m (9.84 ft) cables to connect the SFP+ ports. SFP+ cables are applicable • LSTM1STK 5 m (16.40 ft) to SFP+ ports of the LSW1SP4P0 or LSW1SP2P0. LSWM4STK 10 m (32.81 ft) SFP+ cables are hot • swappable. NOTE: Before installing or removing a cable, wear an ESD-preventive •...
-
Page 24: Sfp Transceiver Module Overview
Table 7 shows the optional 100/1000 Mbps SFP transceiver modules for SFP ports on the LSW1GP16P0 and the 1000 Mbps SFP transceiver modules for the SFP+ ports on the LSW1SP4P0 or LSW1SP2P0. Table 7 Optional SFP transceiver modules Item SFP transceiver module... - Page 25 Installation Guide from the H3C's website before installing SFP or SFP+ transceiver modules.
-
Page 26: Verifying The Installation
Verifying the Installation After the installation, connect the cables. When the switch runs properly, check whether the module is operating properly according to the port LED status.
