HandyTone-701 User's Manual
Ver2.0.1 2016/02/08 作成
Copyright © 2015 cloudippbx.com.

Advertisement

loading
Need help?

Need help?

Do you have a question about the HandyTone-701 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Grandstream Networks HandyTone-701

Summary of Contents for Grandstream Networks HandyTone-701

  • Page 1 HandyTone-701 User's Manual Ver2.0.1 2016/02/08 作成 Copyright © 2015 cloudippbx.com.
  • Page 2 ・ The company will not be responsible for inconsistency in call quality brought about by individual listening skills. ・ The company will not be responsible for the device damage that occurred outside Japan. ・ Please acknowledge that services in HandyTone-701 may stop temporarily without prior notice due to HT- 701’s scheduled maintenance.
  • Page 3 ・ HandyTone‐701 HandyTone-701 is an adaptor used to connect an analog phone device to Agile Phone. To use the device, the customer needs to subscribe to an Internet Service Provider. Customer with no broadband router features needs to provide a separate broadband router.
  • Page 4 English voice saying ENTER A MENU OPTION is played. ※ If already set, a voice saying ENTER A MENU OPTION will be played. 3. After ENTER A MENU OPTION is played, dial 02. An English voice telling HandyTone-701’s IP address will be played.
  • Page 5 ・Setting from Web Browser ④ Click the ADVANCED SETTINGS tab found at the upper portion of the page. Copyright © 2015 cloudippbx.com.
  • Page 6 ・Setting from Web Browser Primary SIP Server： Enter VoIP server. Outbound Proxy： Enter VoIP server. NAT Traversal (STUN)： Select No, butsend keep-alive. SIP User ID： Enter Unique (10 numeric characters) Authenticate ID： Enter Unique (10 numeric characters) Authenticate Password： Enter device password. Name：...
  • Page 7 ・Setting from Web Browser ⑤ Click the ADVANCED SETTINGS tab found at the upper portion of the page. NTP Server： Enter ntp.jst.mfeed.ad.jp. Once done, click Update and Apply respectively. Click Reboot. The device will be restarted and settings will be applied.
  • Page 8 1. Pick-up the handset. 2. From HandyTone-701 connected phone device, enter * * *. From the handset, a voice guidance saying ENTER A MENU OPTION will be played. When you dial *, confirming the status, DHCP mode or STATIC IP mode, is possible.

  • Page 9: Safety Precautions

    Safety Precautions This manual contains precautions to assure user’s safety while using this product. If the precautions are disregarded, the extent of consequences is presented below. This indicates that ignoring or mishandling of this notice might result to death or serious injury to the person. WARNING This indicates that ignoring or mishandling of this notice might result to harm to the person.

  • Page 10: Troubleshooting

    Troubleshooting PROBLEM CAUSE SOLUTION Please plug and unplug from the power source. (Do this a few times). General Failure Please wait at least one minute before you again plug the device to the power source. Ethernet cable is disconnected. Please check the connection of the Ethernet cable. AC adapter is disconnected.
