The LCD panel displays
Settings
3. Press the upper-left (UL) button.
The LCD panel displays
Region
4. Press the lower-right (LR) button.
The LCD panel displays
System
5. Press the lower-right (LR) button.
The LCD panel displays
Network
6. Press the upper-left (UL) button.
The LCD panel displays
Port 1 (WAN)
7. Press the upper-left (UL) button.
The LCD panel displays
Set DHCPV4
8. Select the lower-right (LR) button.
The LCD panel displays
Set Static IPV4
9. Select the upper-left (UL) button.
The LCD panel displays
IPV4 Address
10. Press the upper-left (UL) button.
The LCD panel displays
IPV4 Address
000.000.000.000
11. Press the upper-left (UL) button until the cursor is over the first zero.
The LCD panel displays
IPV4 Address
000.000.000.000
12. Use the lower-left (LL) and lower-right (LR) buttons to decrease and increase the value of the current
digit.
