- Page 1 Sensors Worldwide Technical Description / User’s Guide BTL5-A/C/E/G_-M____-P-S32/KA__ Micropulse Linear Transducer Analog Output/Profile Housing ™...
- Page 2 BTL5-A/C/E/G_ _-M/U_ _ _ _-P-S 32/KA_ _ Micropulse Linear Position Transducer ™ Analog Profile Style 1-800-543-8390 • WWW.BALLUFF.COM...
- Page 3 BTL5-A/C/E/G_ _-M/U_ _ _ _-P-S 32/KA_ _ Micropulse Linear Position Transducer ™ Analog Profile Style Rugged, 2 3 4 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 Rod Style Compact B T L -...
-
Page 4: Table Of Contents
Check functionality ..7 maintaining the permissible ambient conditions. Fault conditions ....7 1.4 Scope Noise elimination ..... 7 This guide applies to the model BTL5-A/C/E/G...P... Micropulse Versions (indicated transducer. on part label) ....7 An overview of the various models Technical Data .... -
Page 5: Function And Characteristics
BTL5-A/C/E/G_ _-M/U_ _ _ _-P-S 32/KA_ _ Micropulse Linear Position Transducer ™ Analog Output/ Profile Housing Function and Characteristics 2.1 Characteristics 2.3 Available stroke lengths and magnets Micropulse transducers feature: The torsional wave arriving atthe end of the waveguide is absorbed —... -
Page 6: Floating Magnets
BTL5-A/C/E/G_ _-M/U_ _ _ _-P-S 32/KA_ _ Micropulse Linear Position Transducer ™ Analog Output/Profile Housing Installation (cont.) Nominal stroke Mounting brackets with isolation bushings and M5 x 22 socket head cap screws, DIN 912, max. tightening torque 2 Nm Fig. 3-1: Dimensional drawing (BTL5...P-S 32 transducer with floating magnet BTL5-P-3800-2) max. -
Page 7: Captive Magnets
BTL5-A/C/E/G_ _-M/U_ _ _ _-P-S 32/KA_ _ Micropulse Linear Position Transducer ™ Analog Output/ Profile Housing Installation (cont.) Black, Nominal stroke round marking Magnet Mounting brackets with isolation bushings and M5 x 22 socket head cap screws, DIN 912, max. tightening torque 2 Nm Fig. -
Page 8: Wiring
BTL5-A/C/E/G_ _-M/U_ _ _ _-P-S 32/KA_ _ Micropulse Linear Position Transducer ™ Analog Output/Profile Housing Wiring Analog Voltage Analog Current 24 V (A, B, G) 24 V (E, C) Analog output, falling Analog output Analog output, rising Analog common Analog common... -
Page 9: Startup
BTL5-A/C/E/G_ _-M/U_ _ _ _-P-S 32/KA_ _ Micropulse Linear Position Transducer ™ Analog Output/ Profile Housing Wiring (cont.) 4...20 mA 10...0 V 0...10 V +24 V Fig. 4-3: BTL5-E10...KA _ _ with processor card/controller, wiring example Startup Check connections Voltage output 10 V... -
Page 10: Technical Data
BTL5-A/C/E/G_ _-M/U_ _ _ _-P-S 32/KA_ _ Micropulse Linear Position Transducer ™ Analog Output/Profile Housing Technical Data The following are typical values at DC 24 V and 25 °C. Fully operational after power-up, with full accuracy after warm-up. Values are with BTL5-P-3800-2, BTL5-P-4500-1 or BTL5-P-5500-2 magnet held at a... - Page 11 BTL5-A/C/E/G_ _-M/U_ _ _ _-P-S 32/KA_ _ Micropulse Linear Position Transducer ™ Analog Output/ Profile Housing Magnet and Control Arm Diagram References Nominal stroke Fig. 3-1: Dimensional drawing (BTL5...P-S 32 transducer with floating magnet BTL5-P-3800-2) Mounting brackets with isolation bushings and M5 x 22 socket head cap screws, DIN 912, max.
-
Page 12: Product
