External input

The EXTERNAL INPUT can be set using
OPTIONS menu entry (see fig.).
Use switch without glow lamp path.
OPTIONS
OPERATING
HOUR
ok
CHANNEL C1
EXTERNAL
INPUT
BUTTON
LCD ILLUMINA-
TION
LANGUAGE
PIN
FACTORY
SETTINGS
INFO
ok
MANUAL
SWITCH
TIMER
INACTIVE

Memory card OBELISK top2

Use memory card
Insert memory card in the timer.
Request savedswitch timings, read to/from
the timer or start Obelisk program.
Memory card OBELISK top2
(No. 907 0 404) after Pro-
gramming etc. remove
and store in cover.
Avoid mechanical overload
or contamination caused by other storage/
transport.
GB
13
