    307070 Time switch TR 610 top2 6100100 TR 612 top2 6120100 1. Basic safety information 2. Proper use Disposal 3. Installation and connection 4 Mounting the time switch Connecting the cable Disconnecting the cable 4. Device description Display & buttons...
  • Page 2 Overview of navigation menu 9 Initial operation 5. Settings and functions Set switching time Change switching times Delete switching program Activating PIN code Setting manual or permanent switching Hour counter Using the OBELISK top2 memo- ry card Resetting the time switch 6.

  • Page 3: Basic Safety Information

    1. Basic safety information WARNING Danger of death through electric shock or fire! Installation should only be carried out by a ¾ ¾ qualified electrician! • The device is designed for installation on DIN top hat rails (in accordance with EN 60715) •...

  • Page 4: Installation And Connection

    3. Installation and connection Mounting the time switch WARNING Danger of death through electric shock or fire! Installation should only be carried out by a ¾ ¾ qualified electrician! click...
  • Page 5 45° cable Load line connection Plug-in screwless termi- nal NC contact Test tap OBELISK top2 memory card (9070404) Mount on DIN top hat rails (as defined in EN 60715) † ¾ Switched voltage-free † ¾ Ensure device cannot be switched on †...

  • Page 6: Connecting The Cable

    Connecting the cable Wiring diagrams 6100100 / 6120100 4 5 6 L 1 2 3 1 2 3 Strip cable to 8 mm (max. 9) † ¾ Insert cable in the open DuoFix® plug-in terminal at 45° † ¾ L 2 cables per terminal position possible To open the DuoFix®...

  • Page 7: Device Description

    4. Device description Display & buttons Programmed switching times Date display Time display Channel status Days of the week C1, C2 from 1 to 7 ON = On OFF = Off Display of the active buttons with the relevant function MENU ...

  • Page 8: Operating Instructions

    Operating instructions 1. Read text line text/symbol represents query 2. Make a decision Modify/ Confirmation Change Press Press...

  • Page 9: Overview Of Navigation Menu

    Overview of navigation menu MENU PROGRAM TIME/DATE MANUAL TIME CHANNEL C1 SET DATE PERM ON CHECK SU--WI PERM OFF MODIFY WEEK OVERR ON DELETE HOLIDAY FORM DATE FORM TIME OPTIONS OPERATING HOUR LCD ILLU- MINATION LANGUAGE FACTORY SETTING INFO...

  • Page 10: Initial Operation

    Initial operation MENU GERMAN RETAIN FORM DATE PROGRAM DELETE FRENCH YEAR PROGRAM MONTH ITALIAN DUTCH FORM TIME HOUR MINUTE SU-WI EUROPE Set language, country, town/city, date, time as well as † ¾ summer/winter time (SU-WI) Press any button and display follows on screen (see figure) †...

  • Page 11: Settings And Functions

    5. Settings and functions Set switching time MENU PROGRAM CHANNEL C1 CHECK MEM FREE MODIFY HOUR DELETE MINUTE MONDAY Switching same switching  COPY SAVE time for time for one day several days = block TUESDAY SAVE L A switching time always consists of a start time and an end time L There are 56 memory cells available Example: Switch on sports hall lighting from Mon–Fri, 7:30 to...

  • Page 12: Change Switching Times

    Press MENU † ¾ Select PROGRAM and press OK to confirm † ¾ Select NEW and press OK to confirm † ¾ Select CHANNEL C1 or C2, confirm with OK † ¾ Select ON (for turn-on times), confirm with OK †...

  • Page 13: Delete Switching Program

    L You can either change or delete a block, i.e. a switching time copied for several days (e.g. Mon-Fri) or a single switching time Change individual switching times Press MENU † ¾ Select PROGRAM and press OK to confirm † ¾...

  • Page 14: Activating Pin Code

    With u DELETE MONDAY etc. individual days can also be † ¾ cleared. Activating PIN code The PIN code is set in OPTIONS via the menu. L If you have forgotten your PIN, call the Theben Hotline. L Have the serial number ready. MENU OPTIONS OPERATING HOURS...

  • Page 15: Setting Manual Or Permanent Switching

    Setting manual or permanent switching Manual or permanent switching can be set via the menu in MANUAL or (in the automatic screen) by button combination (see picture). • Manual control: Reversing the channel status to the next automatic or programmed switching. •...

  • Page 16: Using The Obelisk Top2 Memory Card

    Read in/out saved switching times and device setups in † ¾ the time switch or start Obelisk program Remove memory card after copying etc. † ¾ Avoid mechanical overload and contamination during storage/transport L PC software OBELISK top2 available at www.theben.de...

  • Page 17: Resetting The Time Switch

    Copying OBELISK → TIME This copies the switching program and optionally all time switch settings (e.g. external input, time format etc.) from the memory card in the time switch. Copying TIME →OBELISK This copies all switch programmes and settings from the time switch to the memory card.

  • Page 18: Technical Data

    10 A (at 250 V, cos ϕ = 0,6) Min. switching capacity: 10 mA/230 V AC 100mA/ 24 V AC/DC Switching output: switching of choice of phase is permitted TR 610 top2: suitable for switching SELV (Safe Extra-Low Voltage) Shortest switching time: 1 min Protection rating:...

  • Page 19: Contact

    LED lamps (<2 W): 30 W LED lamps (>2 W < 8 W): 100 W LED lamps (>8 W): 120 W 7. Contact Theben AG Hohenbergstr. 32 72401 Haigerloch GERMANY Tel. +49 7474 692-0 Fax +49 7474 692-150 Hotline Tel. +49 7474 692-369 hotline@theben.de...
