Turn the Robot Brain ON by pressing the Check button. The Controller will automatically link
and pair to the Robot Brain. The Tether Icon will appear on the Robot Brain LCD screen.
Remove the Tether cable from Robot Brain and Controller. They are now communicating
wirelessly as indicated by the Radio Bar icon on the LCD screen. The Robot Brain's LED and
the Controller's Power/Link LED should be blinking green. Congratulations, your Robot Brain
and Controller are now paired!
If the Robot Brain and Controller are not linked (indicated by animated "Searching" icon), turn
them both OFF and repeat the process.
Icon Table
1 2
Animated icon
Programs
Driver Control
Autopilot
Select
3 4
Tether Icon. See
table below for
Settings
explanation.
Searching Icon - Searching for Controller
(not connected).
Tether Icon - Connected by Tether Cable.
Radio Link Icon - Connected by Radio
(number of bars indicates signal strength).
No Radio installed, no Tether connected.
