Keeping the Shaft Supported & Seated in Smart Motors & Assemblies
Having a motor turn a shaft in the VEX IQ system is accomplished easily with only a few
parts. However, without proper shaft support and either a rubber shaft collar and/or a shaft
bushing, the shaft will quickly shift or fall out of your mechanism or Smart Motor.
Improper Support Proper Support
(Shaft can fall out) (Shaft can't fall out)
Improper Support Proper Support
(Shaft can fall out) (Shaft can't fall out)
