Robot Brain Setup
Robot Battery Charging and Usage
Items you need:
• Robot Battery Charger P/N: 228-2743
• Battery Charger Power Cord appropriate for your region
• Robot Battery P/N: 228-2604
See the Battery Safety information in the Appendices. Plug the Battery Charger Power Cord
into Robot Battery Charger. Plug the power cord into an AC outlet. Insert the Robot Battery
into the charger. The LED should turn red. The LED will turn green once the battery is
charged. The battery will continue to trickle (slowly) charge after the LED is green.
LED
Robot Battery Charger LED
86
Turns red
or green.
LED Color
Solid Green
Solid Red
Blinking Green
Blinking Red
Status
Battery is Fully Charged
Battery Charge in Progress
Over Temperature Fault
Battery Fault
