2.4 Top View

Charger Socket
Thermocouple (ch1)
T1 Socket
Thermocouple (ch2)
T2 Socket
Gas Inlet Port
Pressure (+) Port
Pressure (-) Port
Connection for 220V/115V charger (see 10.1)
Connection for thermocouple plug on probe (see 4.1)
Connection for any 'K' type thermocouple probe (see 4.2)
Connection for any 'K' type thermocouple probe (see 4.2)
Connection for In-Line Pump Protection Filter (see 3.1)
Connections for Pressure Tubing (see 4.3)
Connections for Pressure Tubing (see 4.3)
