Playback - Blackmagicdesign HyperDeck Installation And Operation Manual

Playback

Playing Video with HyperDeck
1 Press the 'play' button once for instant playback and you'll see your video on the LCD,
and any displays connected to your HyperDeck's video outputs. When a clip is playing,
pressing 'play' again will loop it continuously. On HyperDeck Studio Mini, pressing play
a third time will let you loop all recorded clips.
NOTE With HyperDeck Studio Pro, you can choose to play back Ultra HD
using single link, dual link or quad link outputs. Refer to the 'Ultra HD Playback
on HyperDeck Studio Pro' section for more information.
2 To skip to the next clip, press the 'next clip' button on the control panel.
3 Press 'previous clip' once to go to the start of the current clip or press twice to skip
back to the start of the previous clip.
Press the play button on your HyperDeck's control panel to play back a clip, and press
the forward or reverse skip buttons to restart the current clip or skip to a different one
If the play button flashes on HyperDecks that record on SSDs, this means the disk is not fast
enough and playback cannot keep up. We recommend you change to a compressed recording
format such as ProRes or DNxHD, or use a faster recommended SSD for uncompressed or Ultra
HD recording.
SSD slots have rotating LEDs to show the unit is in playback mode
01:23:47:08
1080p59.94 Card 2
01:23:47:08
01:23:47:08
DISP INPUT REM
SET
JOG
1080p59.94
1080p59.94
DISP
SET
SSD 2
01:42:56:12
SD 2
SD 2
INPUT REM
JOG
Playback 9 9
01:4
