Blackmagicdesign HyperDeck Installation And Operation Manual page 10

TIP If you play back a video clip that has an associated .MCC file, the closed caption
data will be played out with the video via the SDI output of your HyperDeck.
Ultra HD Playback on HyperDeck Studio Pro
HyperDeck Studio Pro can play back Ultra HD video via single link 6G-SDI, dual link 3G-SDI,
and quad link HD-SDI.
To select your desired Ultra HD playback output:
1 Press the 'disp' button to open the control panel LCD menu.
2 Using the jog/shuttle wheel and 'set' button, select 'video', then '2160p SDI out'.
3 Select your desired output type and press 'set' to confirm. Press the 'disp' button to
close the menu.
Video In
INPUT REM
4K SDI Out
JOG
For HyperDeck Studio Pro, you can choose between single link 6G-SDI,
dual link 3G-SDI or quad link HD-SDI for Ultra HD playback
Jog or Shuttle
You can use the jog or shuttle wheel to shuttle to a particular section at variable speeds. The
more you turn it forwards or backwards, the faster your HyperDeck Studio will play through your
video. Once you've found the section you want to review, press 'play' to resume
normal playback.
If you want to slowly jog through your video frame by frame, press the 'jog' button once to
enable jog operation. Turning the jog or shuttle wheel in the desired direction will then jog
through your video. Pressing the 'jog' button again will return the wheel to shuttle operation.
If your HyperDeck has 'reverse' or 'fast forward' buttons, you can press these buttons to play
through the clip at 2x speed. Press the 'reverse' or 'fast forward' buttons again and the speed
will increase to 4x and then 8x. Once you've found the section you want to review, press 'play'
DISP
to resume normal playback.
SET
DISP
SET
On HyperDecks with fast forward and reverse buttons, press the buttons repeatedly
to gradually shuttle playback forwards and backwards at faster speeds
2160p SDI Out
Single 6G-SDI
Dual 3G-SDI
Quad HD-SDI
INPUT
INPUT
REM
JOG
SSD 2
01:42:56:12
REM
JOG
SSD
01:42:56:12
Playback
2
10 10
