Control Panel Display Menu

Using the Display Menu
Use your HyperDeck's control panel display menu to change your video and audio inputs and
outputs as well as any settings changes you would make in HyperDeck Setup such as trigger
recording, timecode output and your chosen recording codec.
Codec
ProRes HQ
ProRes
ProRes LT
ProRes Proxy
HyperDeck Studio Mini has a list based menu, and HyperDecks that record on SSDs have a
tile based menu, so the position of some settings in the menu may appear slightly different
To change a setting in the menu:
1 Press the 'display' or 'menu' button to display the main menu.
2 Use the jog/shuttle wheel on the front of HyperDeck to highlight different options.
3 Press the 'set' button to confirm a selection.
4 To return to a previous menu, press the 'menu' button on HyperDeck Studio Mini, or
scroll to the 'return' arrow and press 'set.
5 Press the 'display' or 'menu' button to exit.
Description
For high quality compression of Ultra HD using a lower DNxHR
data rate.
For the highest quality HD compression at the maximum DNxHD
data rate.
For extremely high quality HD compression using a low DNxHD
data rate.
For high quality HD compression at a lower DNxHD data rate.
Codec
Record
Trigger
Codec
Uncomp 10-bit
ProRes HQ
ProRes
ProRes LT
ProRes Proxy
Control Panel Display Menu 20 20
