Omron V740-BA50C22A-US Operation Manual

Omron V740-BA50C22A-US Operation Manual

V740-series uhf rfid system reader/writer antenna
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
V740-series
UHF RFID System
Operation Manual
Reader/Writer
Antenna
V740-BA50C22A-US (Bi-static Reader/Writer)
V740-HS02CA (Circular Antenna)
V740-HS02C (Circular Antenna)
Cat.No. RFM – XXX – XX
V740 RFID READER/WRITER, ANTENNA
2005-09, REV.01
1 of 56
OPERATION MANUAL
©OMRON CORPORATION 2005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V740-BA50C22A-US and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Omron V740-BA50C22A-US

Summary of Contents for Omron V740-BA50C22A-US

  • Page 1 V740-series UHF RFID System Operation Manual Reader/Writer Antenna V740-BA50C22A-US (Bi-static Reader/Writer) V740-HS02CA (Circular Antenna) V740-HS02C (Circular Antenna) Cat.No. RFM – XXX – XX V740 RFID READER/WRITER, ANTENNA 2005-09, REV.01 1 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...
  • Page 2 DAMAGES, LOSS OF PROFITS OR COMMERCIAL LOSS IN ANY WAY CONNECTED WITH THE PRODUCTS, WHETHER SUCH CLAIM IS BASED ON CONTRACT, WARRANTY, NEGLIGENCE, OR STRICT LIABILITY. IN NO EVENT SHALL THE RESPONSIBILITY OF OMRON FOR ANY ACT EXCEED THE INDIVIDUAL PRICE OF THE PRODUCT ON WHICH LIABILITY IS ASSERTED.

  • Page 3: Safety Precautions

    A notification that prohibits disassembly when injuries caused by electric shocks may result. Please ensure that all cautions and prohibitions are adhered to, since non-compliance may lead to serious injury or damage, in certain circumstances. V740 RFID READER/WRITER, ANTENNA 2005-09, REV.01 3 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...
  • Page 4 ・ Locations that do not satisfy the specified storage conditions (-25 to +65℃, 35%RH to 85%RH,non- condensing). ・ Locations where the Reader/Writer is exposed to direct sunlight. V740 RFID READER/WRITER, ANTENNA 2005-09, REV.01 4 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...
  • Page 5 If the device fails or is exposed to water (non-waterproof devices or parts), or an unusual smell, smoke, or sparks are detected, immediately refrain from using the device and contact OMRON or a sales representative for service and repair. Continued use of the failed device may result in electric shock or fire.

  • Page 6: Table Of Contents

    3.2 Detailed Command structure .....................49 4. Characteristics(Reference) .................50 4.1 Communications Range ......................50 4.2 Communications Time .......................51 APPENDIX : OUTLINE DRAWINGS.................52 Reader : ( V740-BA50C22A-US) ....................52 Antenna : ( V740-HS02CA，V740-HS02C) ................53 Antenna Cable:..........................54 V740 RFID READER/WRITER, ANTENNA 2005-09, REV.01 6 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...

  • Page 7: Installation And Usage Guide

    V740-HS02CA Bi-static Antenna(Circular) V740-HS02C Bi-static Antenna(Circular) The OMRON V740 RFID Reader (herein after denoted as the V740 Reader) uses RFID (radio frequency identification) technology to read data stored on RFID tags. The V740 reader operates analogous to an SQL (structured query language) server, providing tag data in response to requests from another application.

  • Page 8: Before You Begin

    Affected antennas may be synchronized by a separate user application using a time- multiplexing strategy. – Antenna power can be reduced by reconfiguring the RF Transmit Power setting for the reader. V740 RFID READER/WRITER, ANTENNA 2005-09, REV.01 8 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...

  • Page 9: Authorized Antennas

    Cable Diameter : 5.5mm(0.22’’) Long cable Model: V740-A01-10M Length: 10m(32.8') Insertion Loss: 1.5 dB min. Cable Type:5D-SFA Connector: Reverse TNC to Type N Cable Diameter : 7.6mm(0.30’’) V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 9 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...

  • Page 10: Reader Installation

    E = DC power input not achieved due to uneven mechanical loading. Note: MAC Address is displayed on the lower part of RJ-45 Ethernet port. V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 10 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...
  • Page 11 One to four OMRON Bi-static antennas(V740- 2. Verify that all antennas are securely connected. HS02CA,02C) can be connected to the reader, 3. Connect the reader to the network by plugging a depending on the application requirements. The lower Shielded Ethernet cable into the Ethernet port.

  • Page 12: I/O Interface

    Disconnecting power while booting the V740 20mA max. reader may result in improper startup. 360Ω Photo-coupler input Control capacity 20mA max. 5~10mA typ. Internal resistance 360ohm V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 12 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...

  • Page 13: Reader Configuration

    For example: IP address 10.0.0.10 Subnet mask 255.255.255.0 4. Browse to… http://v740 (dhcp name) or http://10.0.0.101 The V740 reader browser-based interface to the reader is displayed. V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 13 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...

  • Page 14: Reader Service

    3. Type the IP address of the reader to which you want to communicate in the address field of the browser or use Apple’s Bonjour™ protocol to browse to it. V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 14 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...
  • Page 15 10 EPC1 tags fewer than 50 EPC1 tags fewer than 100 EPC1 tags Note: Only the modes that contain EPC1are available on this type of V740 reader. V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 15 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...
  • Page 16 The total is displayed in large red numbers directly over the tags read. This function is not available when Show Raw screen is displayed. V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 16 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...
  • Page 17 Verify that no other tags are in the antenna’s field. 6. Click the Submit Query button to write the data. If the write was successful, the new tag id appears in the bottom pane. V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 17 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...
  • Page 18 3. Click the Save Changes button to save the new settings. IMPORTANT: Do not disconnect power until the save process is complete. (see 1.5.2 Restarting the Reader on page 25). V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 18 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...
  • Page 19 Query rebooting the reader. Once a user program has connected to port 8080, the results of the command will be available. V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 19 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...
  • Page 20 Omit if you access by the static IP address. Default Gateway Select whether the reader uses LAN wired or air interface. LAN(fixed) V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 20 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...
  • Page 21 DHCP) Fallback Default gateway to be used If DHCP server can't be found Optional (in the (none) Gateway when in DHCP mode. case using DHCP) V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 21 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...
  • Page 22 V740 reader as below. (a) Boot message (b) Query page display and query performance (c) Log-in by telnet, SSH Change of setting values Firmware upgrade V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 22 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...
  • Page 23 If Yes, RQL no longer listens on Port 8080 for remote Optional access. RQL is still accessible via an SSH tunnel. It is (disable non- recommended to set 'No' in ordinary use. tunneled RQL) V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 23 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...
  • Page 24 Or the V740 Reader loses the function of I/O control(See section 3). If the V740 Reader loses the I/O function, you should query OMRON to tell the way of recovering the function. V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1...

  • Page 25: Restarting The Reader

    • View Log is used for maintenance of the reader. 1. Click the restart link on the navigation menu. For use by OMRON only. 2. Click the restart button and the OK button on the confirmation dialog. Wait for at least 60 seconds for the reader to boot up.

  • Page 26: Using Safe Mode

    The second is to change settings that are preventing the reader from operating normally. Both of these tasks can be performed via the web interface. V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 26 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...

  • Page 27: Tag Fundamentals

    1 tags. Bit count of EPC code is 96. Byte Contents Check Code (CRC) 8-15 16-23 24-31 32-39 40-47 48-55 EPC Code 56-63 12bytes (96bits) 64-71 72-79 80-87 88-95 96-103 104-111 V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 27 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...

  • Page 28: Specifications

    Dimension .........308 X 286 X 40mm (12.1 X 11.3 X 1.6 in) Weight ..........1.5kg (3.4 lbs) Protection ............IP40 Antenna Dimension ........496X 221 X 70mm Weight .............2.0kg Protection ............IP50 V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 28 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...

  • Page 29: Query Protocol

    Other transport protocols may be used to communicate between the client software and its subjugate readers. The application-level protocol discussed below is neutral with respect to the transport layer. V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 29 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...

  • Page 30: Event/Query Protocol

    Execute any aliases (cursor) repeatedly in the specified term. 2. Tag population/general query is made protocol antenna read count 0x1234 EPC1 0xABCD EPC1 Figure 1 : Conceptual diagram of control flow V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 30 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...

  • Page 31: General Observations, Commands, And Syntax

    In the current state of the art, most protocols do not support addressed ID writes (ID write targets all tag IDs) or disallow tag ID changes entirely. V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 31 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...

  • Page 32: Detailed Command Structure

    In response, all IDs delimitted by LF code are sent. • To query a specific sub class of tags, given a The format is as follows: range of tag ID values: V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 32 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...
  • Page 33 [Query] SELECT protocol_id, id FROM tag_id WHERE antenna_id=1 AND protocol_id='EPC1'; [Res] 1|0xCE791111111111111111<LF><LF> time_out • To query during a specific time: ant1 ant2 ant3 ant4 ant1 ant2 V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 33 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...
  • Page 34 The max of the difference can be calculated by summing up the time caused by the reasons. You need consider time lag to avoid mutual interface due to time sharing. V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 34 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...
  • Page 35 SELECT command will read tags in milliseconds. Note(*1): If you specify 'read_count' on 'EPC1' protocol, the reader returns '1' due to the search algorithm. V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 35 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...

  • Page 36: Id Write - Writing Data To Tag

    A0987654 written WHERE antenna_id tag_id [1...4] Specifies antenna used read a tag protocol_id tag_id String 'EPC1' 'EPC1' Specifies protocol used read a tag. Must be uppercase. V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 36 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...
  • Page 37 A0987654 Specifies WHERE antenna_id tag_id [1...4] antenna used update a tag protocol_id tag_id String 'EPC1' 'EPC1' Specifies protocol used update a tag. Must be uppercase. V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 37 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...
  • Page 38 BA09876 54321 WHERE antenna_id tag_id [1...4] Specifies antenna used update a tag protocol_id tag_id String 'EPC1' 'EPC1' Specifies protocol used update a tag. Must be uppercase. V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 38 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...
  • Page 39 A0987654 Specifies WHERE antenna_id tag_id [1...4] antenna used update a tag protocol_id tag_id String 'EPC1' 'EPC1' Specifies protocol used update a tag. Must be uppercase. V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 39 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...
  • Page 40 Every 500 milliseconds, the cursor executes for 250 Following the command, an empty event (only LF milliseconds querying for tags. The remaining 250 code) is returned. The command returns the RQL V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 40 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...
  • Page 41 V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 41 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...
  • Page 42 Example is as follows: SET separator='#'; SELECT id, protocol_id, antenna_id FROM tag_id WHERE protocol_id='EPC1'; The response would be as follows. 0xCE85123467890ABCDEF#1#1<LF><LF> Table7 : Table Schema - Reader Control V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 42 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...
  • Page 43 = ON on/off. ON, OFF repeat Integer Sets a cursor to keep running separator character except ‘|’ Changes the separator in the output format of a query. V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 43 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...

  • Page 44: Get Information

    Shannon) current_time Settings String 2006-01- Requests current time of the 01T00:01:39.8 reader. 91808 FROM Firmware Table information about reader's firmware. Table Settings information about reader's settings. V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 44 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...

  • Page 45: Errors

    Unknown protocol Indicates nonexistent protocol Syntax Error Syntax error or spelling mistake etc Invalid argument 0101 : Unknown setting ERROR_INVALID Time is invalid _DATA Unknown protocol ID V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 45 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...
  • Page 46 Tag data access failed Table name on update command is invalid ERROR_UNKNO Error getting entry Error getting ip address entry Error getting netmask entry Error getting gateway entry V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 46 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...

  • Page 47: Protocol Specific Functionality And Parameter Settings

    2nd reader, a ‘Talk’ command must be sent to change the tag to active mode.(for more detailed information about the status of the tag see 'Communication Interface Specification' for EPC1) V740 RFID READER/WRITER, ANTENNA 2005-09, REV0.1 47 of 56 OPERATION MANUAL ©OMRON CORPORATION 2005...

  • Page 48: Examples

    DECLARE query1 CURSOR FOR SELECT id FROM tag_id WHERE antenna_id=1 AND Line 2 protocol_id='EPC1' SET time_out=500; SET AUTO query1=ON, repeat=1000; Reader 2 antenna 1 V740 RFID READER/WRITER, ANTENNA 2005-09, REV.01 48 of 56 OPERATION MANUAL OMRON CORPORATION 2005...

  • Page 49: I/O

    Writing “*” instead of “1” or “0” starts to read the statuses of the connectors. < Response format > Coomand Response LF LF “CC” Code “00” V740 RFID READER/WRITER, ANTENNA 2005-09, REV.01 49 of 56 OPERATION MANUAL OMRON CORPORATION 2005...

  • Page 50: Characteristics(Reference)

    *. 6dB attenuator is attached at the time of measurement with a Liner polarization antenna. 3dB attenuator is attached at the time of measurement with a Circular polarization antenna. V740 RFID READER/WRITER, ANTENNA 2005-09, REV.01 50 of 56 OPERATION MANUAL OMRON CORPORATION 2005...

  • Page 51: Communications Time

    One may use the communication time value as a reference when setting time out values in the RQL command. Class1/1b Tags 1000 Number of Tags V740 RFID READER/WRITER, ANTENNA 2005-09, REV.01 51 of 56 OPERATION MANUAL OMRON CORPORATION 2005...

  • Page 52: Appendix : Outline Drawings

    APPENDIX : OUTLINE DRAWINGS Reader : ( V740-BA50C22A-US) Material : Aluminium V740 RFID READER/WRITER, ANTENNA 2005-09, REV.01 52 of 56 OPERATION MANUAL OMRON CORPORATION 2005...

  • Page 53: Antenna : ( V740-Hs02Ca，V740-Hs02C)

    Antenna : ( V740-HS02CA，V740-HS02C) Material : Aluminium V740 RFID READER/WRITER, ANTENNA 2005-09, REV.01 53 of 56 OPERATION MANUAL OMRON CORPORATION 2005...

  • Page 54: Antenna Cable

    Antenna Cable: Short cable (V740-A01-3.0M) Long cable ( V740-A01-10M) V740 RFID READER/WRITER, ANTENNA 2005-09, REV.01 54 of 56 OPERATION MANUAL OMRON CORPORATION 2005...
  • Page 55 Revision History RFM - 002 - 01 Catalog No. Revision Code Revision Code Date Reason for revision/revised page 2005/11 First edition V740 RFID READER/WRITER, ANTENNA 2005-09, REV.01 55 of 56 OPERATION MANUAL OMRON CORPORATION 2005...
  • Page 56 OMRON ELECTRONICS LLC 1 East Commerce Drive, Schaumburg, IL 60173 U.S.A. Tel: (1)847-843-7900/Fax: (1)847-843-8568 Up-to-date information on RFID Systems can be accessed at OMRON's web site at http://www.omron.com/card/rfid/ Up-to-date information on RFID Systems can be accessed at OMRON's web site at http://www.omron.com/card/rfid/ Printed in Japan Cat.
