Omron DeviceNet WD30 Datasheet

Unit Descriptions
DeviceNet Wireless Link
WD30 0
Wireless DeviceNet Link Connects Slaves
without Wires
• Up to 3,200 I/O points can be communicated through a single
Unit.
• Uses spread spectrum technology for superior noise resistance
in manufacturing environments.
• Compact construction was a design priority to allow easy instal-
lation.
• Long-range communications have been achieved with a relay
function (3 repeaters max.).
• Message communications are supported.
Ordering Information
■ List of Models
Name
DeviceNet Wireless Master
DeviceNet Wireless Slave
Magnetic Base Antenna (1)
Note: The WD30-AT001 Magnetic Base Antenna can be used with the WD30-ME, WD30-ME01, WD30-SE, and WD30-SE01.
■ Optional Accessories (Micro Connectors)
Name
Shielded T-branch Connector
Cable with Shielded Connectors
Shielded Terminator
■ Included Accessories
The following accessories are included with a DeviceNet Wireless
Master or DeviceNet Wireless Slave.
• Two antennas
• DeviceNet Wireless Units Instruction Sheet
• Sticker
• Two M4 mounting bolts (with nuts, flat washers, and spring wash-
ers)
Number of I/O points (words used)
1,600 inputs max. (100 words)
1,600 outputs max. (100 words)
512 inputs max. (32 words)
512 outputs max. (32 words)
---
Model
DCN2-1
DCA1-5CN@@W1
DCA1-5CN@@F1
DRS2-1
WD30-ME
(WD30-SE)
Model
WD30-ME
WD30-ME01
WD30-SE
WD30-SE01
WD30-AT001 (See note.)
Connector with one branch
Cables with connectors on both ends
Cables with a connector socket on one end
Terminator with plug connector
■ Optional Accessories
(Configurator Software)
Name
Configurator (PC Card)
Configurator Software
DeviceNet Wireless Link
WD30-SE01
(WD30-ME01)
Antenna style
Pencil antenna
Magnetic base antenna
Pencil antenna
Magnetic base antenna
---
Specifications
Model
3G8E2-DRM21-EV1
WS02-CFDC1-E
WD30
185
