External AC Fuses ⎯ Recommended Rating
The site's AC supply quality is of great importance. In general, a site with better AC supply
quality (stable nominal voltage) may use smaller breakers.
For Flatpack 1500 sys-
tems use the recom-
mendations in
205VAC table, if you
are sure the available
AC mains voltage will
not drop below
205VAC.
OR
If you are unsure ⎯ or
know that the voltage
may drop below
205VAC ⎯ use the
185VAC table recom-
mendations.
Doc 2014385, v2
For Flatpack 1800 sys-
tems use the recom-
mendations in
205VAC table, if you
are sure the available
AC mains voltage will
not drop below
205VAC.
OR
If you are unsure ⎯ or
know that the voltage
may drop below
205VAC ⎯ use the
185VAC table recom-
mendations.
Doc 2014386, v2
Note: The above recommendations apply for use of Thermal magnetic circuit breaker, type Siemens 5SX or 5SY series, MG C60H
series or similar. For more information regarding External AC fuses and other types of fuses, please read the article 2014385 for
Flatpack 1500 systems or the article 2014386 for Flatpack 1800 systems on the CD, 356802.CD3.
