Plancha Portable BBQ
FEATURES:
• Versatile European style portable BBQ , ideal
for all occasions
• Solid steel vitreous enamel cooking hotplate
with sides
• Cooking area (mm): 2 Burner - 440 W x 360 D
4 Burner - 690 W x 360 D
• Powerful 8MJ/hr stainless steel burners with
piezo ignition
Model No. GM152-029
FOR OUTDOOR USE ONLY
DO NOT OPERATE THIS APPLIANCE BEFORE READING THE INSTRUCTION BOOKLET
DO NOT PLACE ARTICLES ON OR AGAINST THIS APPLIANCE
DO NOT STORE CHEMICALS OR FLAMMABLE MATERIALS OR SPRAY AEROSOLS NEAR THIS APPLIANCE
DO NOT OPERATE THE APPLIANCE INDOORS
DO NOT OPERATE IN AN ENCLOSED AREA
ACCESSIBLE PARTS MAY BE VERY HOT. KEEP YOUNG CHILDREN AWAY.
Minimum clearances from combustible materials: 600mm
Retain these instructions for future use.
Important: The installer or seller must leave these instructions with the consumer.
3945-06/14
• Pull out internal drip tray ensures quick
no-mess cleaning
• Durable powder coated construction
• Side handles and lid for easy transport and
storage
• Lid can be used as a splash back
Model No. GM152-033
Advertisement
Table of Contents
Related Manuals for Gasmate GM152-029
Summary of Contents for Gasmate GM152-029
- Page 1 4 Burner - 690 W x 360 D • Lid can be used as a splash back • Powerful 8MJ/hr stainless steel burners with piezo ignition Model No. GM152-029 Model No. GM152-033 FOR OUTDOOR USE ONLY DO NOT OPERATE THIS APPLIANCE BEFORE READING THE INSTRUCTION BOOKLET...
-
Page 2: Table Of Contents
GENERAL INFORMATION Contents Specifications Barbecue specifications can be found on the data label Section Page attached to the barbecue body. Gas Cylinder Use & Safety General Information This is a low pressure barbecue and must only be used General Assembly with the hose and regulator supplied. - Page 3 T his barbecue is only to be used and stored outdoors. Nominal Hourly Gas Consumption Number of Injector Total Gas Model No. Type BBQ Burners Size Consumption Pressure Ø 0.75mm GM152-029 16.9 MJ/h 2.75 kPa MJ/h each 8.35 MJ/h LPG/ ULPG Ø 0.75mm GM152-033 33.8 MJ/h 2.75 kPa MJ/h each...
-
Page 4: General Assembly
GENERAL ASSEMBLY LIGHTING PROCEDURE Before lighting your barbecue for the first time, read the Connecting & Disconnecting to Gas Source instructions fully to ensure the barbecue is assembled Familiarise yourself with the general information and safety correctly and is ready for use. guidelines located at the front of this manual. -
Page 5: Operating Procedure
Burner Operation & Ignition System Check Problem Possible Reason Solution Valve on cylinder is closed Open valve on cylinder Control knob is closed Turn knob to high when lighting Burner will not ignite Piezo igniter is faulty Use a long barbecue match inserted through the hole on side of barbecue Burner has gone out Check that the gas bottle is not... -
Page 6: Parts List
PARTS LIST GM152-029 (2 Burner) GM152-033 (4 Burner) Also included: LPG cylinder hose assembly. -
Page 7: Assembly Instructions
ASSEMBLY INSTRUCTIONS Remove any transit protection material. Estimated Assembly Time: 10 minutes. Remove all contents from the carton packaging. Make sure all parts are present before attempting assembly. Once the BBQ is fully assembled, go back and check to make certain all the bolts are secure. Tighten again using the screwdriver provided if necessary. 4 Burner model is shown. -
Page 8: Leak Test Instructions
ASSEMBLY INSTRUCTIONS Step 7 Step 5 Step 6 Turn on the gas cylinder ensuring Offer the hose assembly up to the Attach the regulator to your gas that all of the controls on the BBQ are connection point on the BBQ. Tighten cylinder. -
Page 9: Care And Maintenance
CARE & MAINTENANCE As with all appliances, proper care and maintenance will Cleaning the Drip Tray keep them in top operating condition and prolong their life. To avoid fat or grease dripping from the barbecue remove Your new gas barbecue is no exception. By following these and empty the drip tray after each use. -
Page 10: Safe Locations
figures - the same principles apply to any other shaped area. Gasmate is a registered trademark of: Sitro Group Australia Pty Ltd www.sitro.com.au ® Aber, Hamilton, N.Z. www.gasmate.co.nz Gasmate ® is a registered trademark of: Sitro Group Australia Pty Ltd www.gasmate.com.au Aber, Hamilton, N.Z. www.gasmate.co.nz... - Page 11 This page has been left intentionaly blank...
