Clas Ohlson KT-3268 Instruction Manual

Clock Radio
Art.no 18-2924 Model KT-3268 UK VERSION
36-5775 KT-3268 NORDIC
Please read the entire instruction manual before using the product
and then save it for future reference. We reserve the right for
any errors in text or images and any necessary changes made
to technical data. In the event of technical problems or other
queries, please contact our Customer Services.
Safety
• The product should not be taken apart or modified. Certain
non-shielded components inside the clock radio's casing
carry dangerous current. Contact with these can lead to fire
or electric shock.
• The clock radio is designed for indoor use only.
• The clock radio should only be connected to a wall outlet
with a 230 V, 50 Hz power supply.
• Never expose the product to high temperatures from
cookers, radiators or other types of heat sources. Never
subject the clock radio to dusty environments, heavy
vibration, impacts, humidity or moisture.
• Never run its mains lead around sharp edges/corners or in
such a way where its lead risks being pinched or damaged
in some other fashion. Place the mains lead where there is
no risk of people tripping over it.
• Do not place the clock radio where there is a risk of it falling into
water or other liquid. Do not place any objects containing
liquid on the clock radio, such as vases, drinks, etc.
• Do not cover the clock radio. Do not place the clock radio
on soft, unstable surfaces such as on blankets, comforters
or similar. Always place it on a solid flat surface to prevent it
from possible overheating. Make sure to keep at least 5 cm
of free space around the clock radio.
• Switching off the clock radio with its power switch only
puts it into standby mode. It does not totally cut it off from
the mains. Pull the plug from the wall socket to disconnect
the clock radio completely from the mains.
• Remember always to protect your hearing. Listening on
high volume for prolonged periods can lead to permanent
hearing loss.
• The clock radio must only be repaired by authorised service
technicians and only using genuine spare parts.
GREAT BRITAIN • customer service tel: 0845 300 9799 e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.com/uk
Buttons and functions
1
2
3
4
8
9
10
1. [ VOL+/AL2 ] volume up, alarm 2 settings
2. [ VOL-/AL1 ] volume down, alarm 1 settings
3. [ SNOOZE/DIMMER/SLEEP ] settings
4. [ MEMORY/TIME SET ] station presets, time settings
5. [ TUNING-/HOUR ] Back, hour settings
6. [ TUNING+/MINUTE ] Forward, minute settings
7. [ /FUNCTION ] On/off, function settings
8. PM indicator, 12-hour clock only
9. Alarm 1 indicator with "buzzer" alarm
5 10. Alarm 1 indicator with radio alarm
6 11. Sleep timer indicator
12. Alarm 2 indicator with "buzzer" alarm
7 13. Alarm 2 indicator with radio alarm
14. Mains lead
15. FM aerial

Operating instructions

Batteries
11
• Batteries are used for backup which preserve time settings
12
during a power cut.
• The display will not show the time during a power cut but all
13
settings will be saved.
Note: The alarm will not sound when run strictly on the batteries.
1. Open the battery cover on the bottom of the clock radio.
2. Insert 2 × AA/LR06 batteries. Note the polarity markings in
the battery compartment to ensure correct battery insertion.
14
3. Refit the battery cover.
15
