Summary of Contents for DAITEM SH402AX
-
Page 2: Table Of Contents
If the user does access these parts, the product guarantee will be considered null and void and DAITEM shall not be held responsible for any problems. Touching the siren’s internal parts and/or electronic components can damage the product. Furthermore, the siren is designed in such a way that these parts and components do not need to be accessed for operation or maintenance purposes. -
Page 3: Introduction
• Some functions are only available with versions 2.0.0 or later (press on the control panel keypad to check the version). • the operating differences with former ranges are described in the compatibility booklet available in the Daitem installers section at www.daitem.co.uk. Following Vocal message a command... -
Page 4: Preparing The Siren
Example: The system is in Armed Partial 2 mode but the siren has a battery fault. When the “system status query” order is sent from the keypad or remote control, the control panel and siren issue the following vocal messages: Bip, system_status, armed Partial 2, “Bip, armed Partial 2, bip, 12/03 at 12:00, Fault, Voltage,... -
Page 5: Recognition Programming
3. Position the power pack on the SH402AX guide rails. A12260A0963C SH402AX Coller sur certif A12260A0963C 4. Slide the power pack downwards until it is locked into place. SH402AX Locking key A12260A0963C SH402AX Coller sur certif A12260A0963C 5. guarantee sticker Remove the pre-cut part of the sticker and stick it to the guarantee certificate in the... -
Page 6: Setting The Parameters
® Daitem installers section at www.daitem.co.uk. The control panel and siren must be in installation mode to set the siren’s parameters. If they are not, enter: master code then “bip, installation... -
Page 7: Delayed Alarm Sounding Upon Intrusion
4.1 Delayed alarm sounding upon intrusion Siren alarm sounding can be delayed by 60 seconds maximum. This gives users enough time to disarm the system before the alarm siren sounds if, for instance, they have pressed the wrong button. To delay sounding, enter: siren n°... -
Page 8: Indication Of Audible Signals And Door Bell
4.5 Indication of audible signals and door bell This function is factory-set to be enabled. It can be deactivated if required. To do this, enter: siren n° 0: disabled 1: enabled Factory setting: 1 4.6 Validation of radio link in installation mode This function is used to validate the radio link test in installation mode on 1 of the 2 radio bands. -
Page 9: Protection System Armed Indication
4.9 Protection system armed indication When this function is enabled, the siren indicates that the system is armed either by issuing a series of 4 beeps or the voice message “bip, bip, bip, bip, Protection active”. This function can be disabled. siren n°... -
Page 10: Radio Tamper
4.13 Radio tamper If the radio links are deliberately tampered with, the siren is triggered. To activate or deactivate the radio tamper system, enter: siren n° 0: disabled 1: enabled Factory setting: 1 4.14 Allocation of siren to alarm group To allocate the siren to one or several alarm system groups, enter: siren n°... -
Page 11: Checking
4.16 Checking To check parameter-setting, enter: siren n° parameter n° example, to check on siren n° 1, parameter 4: duration of sounding, enter: “4, bip, 9, 0” 4.17 Deletion of parameters • To delete a parameter, enter: siren n° parameter n°... -
Page 12: Installing The Siren
5. Installing the siren 5.1 Choosing the best place to install the siren iMPoRtAnt: make sure there is a distance of at least 2 metres between each product, except between two detectors. The siren should preferably be placed: • at a height, •... - Page 13 2. • For the siren to be installed there must be a space of 6 cm to the left of the base, 4 cm above and 18 cm below. This clearance allows for the siren to be easily opened or locked. •...
-
Page 14: Performing A Real Test
6. Performing a real test Testing triggering when there is an attempt to remove the siren 1. Loosen the siren locking screw. iMPoRtAnt: the sounding level of the siren 2. Open the siren. can cause hearing disorders. the necessary precautions must therefore be taken before 3. - Page 15 The siren also provides vocal indication of faults following a command issued from a control unit: Commands Vocal messages Disarm “bip, off..alarm system or Fault system” Disarm group “bip, off...” “bip, off Group X... alarm system or Fault Voltage siren or Fault system” Arm with time delay “bip, armed...
-
Page 16: Changing The Battery
• the lithium battery pack must be replaced by the same type of pack with the same technical characteristics, i.e. 2 x (3.6 V – 13 Ah). • We advise you to use the DAiteM BatLi22 pack available in the catalogue in order to guarantee individual safety and equipment reliability. - Page 17 Parameter description Parameter-setting Factory Possible values Page sequence parameter Selection of speech ** 4 * siren n° * 17 * ? ** 0: French 0: French synthesis system 1: Italian language 2: German 3: Spanish 4: Dutch 5: English Triggering upon intrusion ** 4 * siren n° * 20 * ? ** 1: single or 0: disabled confirmed...
- Page 18 9. Caractéristiques techniques technical specifications SH402AX siren Acoustic level 109 dB at 1 m Sounding duration 20 s to 180 s Indoor sounding 3600 Hz to 4200 Hz with 6 Hz modulation Fire sounding 700/900 Hz, sounding duration: 5 min.
- Page 19 (see telephone number at the back of the alarm system installation manual) or check the web site at: www daitem co uk a team of qualified technicians will advise you what to do.
