Summary of Contents for DAITEM SH426AX
-
Page 2: Table Of Contents
If the user does access these parts, the product guarantee will be considered null and void and DAITEM shall not be held responsible for any problems. Touching the siren’s internal parts and/or electronic components can damage the product. Furthermore, the siren is designed in such a way that these parts and components do not need to be accessed for operation or maintenance purposes. - Page 3 • the operating differences with former ranges are described in the compatibility booklet available in the Daitem installers section at www.daitem.co.uk. In addition to the protection provided by the control panel with built-in siren and keypad, the external siren with vocal messages and flashing strobe makes it possible to:...
-
Page 4: Preparing The Siren
Example: The system is in Armed Partial 2 mode but the siren has a battery fault. When the “system status query” order is sent from the keypad or remote control, the control panel and siren issue the following vocal messages: “Bip, system_status, armed “Bip, armed Partial 2, Partial 2, bip, 12/03 at 12:00, Fault,... - Page 5 3. Lift up the screw cover and remove the 4. guarantee sticker screw from its slot. Remove the pre-cut part of the sticker and stick it to the guarantee certificate in the user manual supplied with the control panel. If you are adding the siren to an existing system, use the guarantee sticker provided with this product.
-
Page 6: Recognition Programming
3. Recognition programming Recognition programming allows the siren to be recognised by the control panel. It must be done with the control panel and siren in installation mode. If they are not in installation mode, enter: then master code installer code iMPoRtAnt •... -
Page 7: Setting The Parameters
® Daitem installers section at www.daitem.co.uk. The control panel and siren must be in installation mode to set the siren’s parameters. If they are not, enter: master code then “bip, installation... -
Page 8: Type Of Sounding
4.3 Type of sounding To modify the type of siren sounding, enter: 0: internal siren n° 1: external Factory setting: external 4.4 Sound level of disarm and arm command indications For greater user-friendliness, the sound level can be increased or decreased. To do this, enter: siren n°... -
Page 9: Modification Of Speech Synthesis System Language
4.8 Modification of speech synthesis system language The French language can be replaced by another language according to the user’s nationality. To do this, enter: siren n° 0: French 3: Spanish 1: Italian 4: Dutch Factory setting: 0 2: German 5: English 4.9 Triggering upon intrusion The alarm is factory-set to be triggered as soon as an intrusion is detected. -
Page 10: Radio Tamper
4.13 Radio tamper If the radio links are deliberately tampered with, the siren is triggered. To activate or deactivate the radio anti-tamper system, enter: siren n° 0: disabled 1: enabled Factory setting: 1 4.14 Duration of flashing To modify the duration of flashing, enter: siren n°... - Page 11 How the different functions work: • duration of flashing (parameter 5) • break-in indication (parameter 35) • visual localisation of flashing strobe (parameter 36) Duration of flashing: 2 min Break-in indication: enabled or disabled 2 min Visual localisation: disabled Duration of flashing: 5 min Break-in indication: enabled 3 min 2 min...
-
Page 12: Allocation Of Siren To An Alarm Group
4.17 Allocation of siren to an alarm group To allocate the siren to one or several alarm system groups, enter: siren n° groups from 1 to 8 depending on the type of control panel Factory setting: all groups example, to allocate siren n° 1 to Group 2 and Group 3, enter: 4.18 Type of indication 5 vocal messages are available in order to personalise indications. -
Page 13: Anti-Tamper Switch Triggering
4.19 Anti-tamper switch triggering To modify the conditions under which the anti-tamper switch will activate the siren, enter: siren n° 0: enabled 24 h/day 1: enabled if system totally armed Factory setting: 1 4.20 Fire alarm indication To modify the fire alarm indication, enter: siren n°... -
Page 14: Installing The Siren
5. Installing the siren 5.1 Choosing the best place to install the siren iMPoRtAnt: make sure there is a distance of at least 2 metres between each product, except between two detectors. The siren should preferably be placed: • at a height, •... -
Page 15: Fixing The Siren In Place
5.3 Fixing the siren in place The siren can be fixed in two different ways: Pozidriv 2 1. • Remove the tamper mechanism • Remove the two fixing washers located washer located at the back of the at the back of the base. Remove any base. -
Page 16: Performing A Real Test
2. Position the siren open at an angle of 45° (A) in relation to the base and insert the pivots on the 45° base into the hinges. (A) 45° 3. Close the siren and lock it using the screw located inside the product. -
Page 17: Maintenance
7. Maintenance 7.1 Fault indications The control panel supervises and identifies the siren. It monitors the state of the: • power supply, • radio link, • tamper contact. If a fault is memorised the control panel issues a voice message to indicate the fault following a system command (see §... -
Page 18: Changing The Battery
• the lithium battery pack must be replaced by the same type of pack with the same technical characteristics, i.e. 2 x (3.6 V – 13 Ah). • We advise you to use the DAiteM BatLi22 pack available in the catalogue in order to guarantee individual safety and equipment reliability. - Page 19 Parameter description Parameter-setting Factory Possible values Page sequence parameter Selection of speech ** 4 * siren n° * 17 * ? * * 0: French 0: French synthesis system 1: Italian language 2: German 3: Spanish 4: Dutch 5: English Sounding level ** 4 * siren n°...
- Page 20 Parameter description Parameter-setting Factory Possible values Page sequence parameter Type of warning ** 4 siren n° * 72 ? ** 3: flashing 0: disabled indication 1: sounding 2: sounding and flashing 3: flashing 4: vocal message n° 1 + flashing N°...
-
Page 21: Technical Data
9. Technical data technical specifications SH424AX, SH425AX, SH426AX, SH424Ai sirens Acoustic level 109 dB at 1 m Sounding duration 20 s to 180 s Internal sounding 1400 Hz to 1600 Hz Fire sounding 700/900 Hz, sounding duration: 5 min. Transfer of Arm/Disarm indications...
