Summary of Contents for DAITEM SH601AU
-
Page 2: Table Of Contents
Contents Foreword....................................3 1. Introduction ..................................4 2. Operation .................................... 5 3. Preparation ..................................6 3.1 Guarantee sticker to be returned ..........................6 3.2 Product label to be kept..............................6 3.3. Activating the pendant ..............................6 4. Recognition programming ............................... 7 4.1 Programming for use with the control panel ........................ -
Page 3: Foreword
Foreword We would like to thank you for buying an alarm pendant. To install the pendant in the best conditions, we advise you to do the following: 1. read the precautions to be taken (below) as well as the “Introduction” and “Operation” chapters, 2. -
Page 4: Introduction
1. Introduction The pendant can be used to send messages 24 hours a day whether the alarm system is armed or disarmed. Depending on its configuration, the pendant can be used to: - transmit alarm messages to a remote monitoring service or to an individual’s phone via the telephone dialler, - trigger an audible alarm via the system’s sirens, - activate beeping on the alarm control panel. -
Page 5: Operation
2. Operation • The push-button can also be reprogrammed to send “Comfort” Push-button type commands (see chapter on “Advanced programming”) in and LED Sliding part order to: Quick- - trigger a fire alarm, fastener - activate beeping or the door bell function on the control panel, - operate an electrical device or lighting via external receivers or remote-controlled sockets. -
Page 6: Preparation
3. Preparation 3.1 Guarantee sticker to be returned 3.3. Activating the pendant This operation should only be performed when the pendant is first Remove the pre-cut part of the used: sticker and stick it to the guarantee Guarantee certificate in the user manual sticker LED ON supplied with the control panel. -
Page 7: Recognition Programming
4. Recognition programming IMPORTANT: when performing recognition programming, the product does not need to be placed next to the control panel (or dialler). In fact, we advise you to move it away slightly (place the product at least 2 m away). 4.1 Programming for use with the control panel Programming makes it possible for 2. -
Page 8: Programming For Use With The Dialler
4.2 Programming for use with the dialler IMPORTANT: the pendant cannot be recognised directly by a dialler alone SH511AX, SH512AX, SH513AX and SH514AX. The pendant is only programmed 2. Perform the next programming step: to operate with a dialler when LED ON there is no alarm control panel in the system. -
Page 9: Main Configuration Operations
5. Main configuration operations The sliding part and the push-button are factory-programmed for the “Silent alarm” command. Pendant programming makes it possible to customise the command sent by the sliding part and/or push-button, depending on the user’s needs: 1. Choose whether you want the sliding part or the push-button to trigger the alarm. 2. - Page 10 A. Programming sequence Each digit in the command n° corresponds to the number of times the push-button is pressed: Number of times pressed Choice of Trigger chosen command n° digit digit Alarm: 22 Press twice Press twice Push- Press button once Silent alarm Press twice...
- Page 11 B. Example of programming • Programming the sliding part to trigger on “Alarm”: - to select the sliding part, press the push-button: twice - the command n° corresponding to the “Alarm” is: 22 Pull the sliding part Press and Press twice Press for 5 s.
-
Page 12: Assembly
6. Assembly 6.1 Assembling the quick-fastener and neck cord Assemble the quick-fastener and insert the neck cord as shown below: Neck cord IMPORTANT: not use the breakaway Quick-fastener release. The breakaway release provides additional safety by releasing the neck cord if it is pulled on too hard. The neck cord and quick-fastener are delivered in the same box. -
Page 13: Assembling The Clip Holder
6.2 Assembling the holder The pendant can be clipped to the holder: 1. Holder clipped to a belt 2. Holder fixed to a wall: Clip the pendant on the holder. A. Before fixing the holder, place it with the pendant close to the fixing location and check Holder the radio link with the control panel (or dialler). -
Page 14: Testing Operation And Radio Coverage In Test Mode
7. Testing operation and radio coverage in test mode IMPORTANT: Whatever the command sent by the sliding part or push-button: • the advantage of the test mode is being able to test the pendant without reducing the radio range and: - with sounding that lasts a shorter time: control panel (3 s.), siren (5 s.) - without triggering telephone transmission, •... - Page 15 3. Test radio coverage: The procedure described below must be followed to test radio coverage: Pull down on the sliding part of the pendant in each place occupied by the user (each room, garage, cellar, loft, garden, etc.) in order to check that the radio link with the control panel (or dialler) works. You will need to do this with the help of a second person.
-
Page 16: Performing A Real Test
8. Performing a real test IMPORTANT • You are now going to perform a real test in user mode. Depending on the command sent by the sliding part or the push-button, this test may trigger the alarm devices and telephone transmission. •... -
Page 17: Advanced Programming
9. Advanced programming 9.1 “Comfort” type application REMINDER: the push-button can also be reprogrammed to send “Comfort” type commands (green LED). • General commands: using the table below, choose a command n° then programme the push-button using the sequence described in step 3 of the chapter on “Main configuration operations” Command description Command Control panel response... -
Page 18: Programming A Pendant Relayed To A Control Panel
2. Configure the pendant to be recognised by the external receiver or remote-controlled socket. green led red led LED ON LED OFF 10 s max. 1. Press and hold the pendant push- 2. When the pendant LED flashes green, 3. The programming LED on the button until the end of the step 3. -
Page 19: Battery Status Indication
10. Battery status indication 11. Technical data Testing the battery status • Radio: - transmission: TwinBand ® (434.5/869 MHz) The system control panel or telephone dialler do not - ERP (effective radiated power): 10 mW max. provide a “batteries flat” indication. - average radio range: 200 m in free field conditions •... - Page 20 Address: F-38926 Crolles Cedex - France Product type: Alarm pendant team. Trade mark: Daitem • Product information can be found on the product label We declare under our sole responsibility that the product to which this on the last page of this manual.
