Summary of Contents for Ganz zn-d9024nha
-
Page 2: Table Of Contents
Thank you for your purchase of this product. PRODUCT FEATURES Before operating the product, please read this instruction manual High resolution surveillance camera with a built-in 1/4- type CCD. carefully to ensure proper use of the product. Integrated varifocal lens allows for versatile application and easy instal- Please store this instruction manual in a safe place for future refer- lation. -
Page 3: Safety Precautions
(8) Be sure to use screws suitable for the type of material to which the camera is SAFETY PRECAUTIONS being mounted. (9) Do not allow the camera to be subjected to strong impacts or shocks. The The installation should be made by a qualifi ed service person and should camera could be damaged by improper handling or storage. -
Page 4: Parts Description
PARTS DESCRIPTION Exterior Camera body interior Surface mount cover Body cover Inner cover Positioning of the lens body angle/focus lever varies depending on the lens. The levers are marked with Lens the following guides. Please refer to these marks for operation when using the product. -
Page 5: Installation And Adjustment
INSTALLATION AND ADJUSTMENT Attaching the unit Attaching to the surface of the ceiling or wall You can use the following three methods to attach the unit. Please This section explains how to install the unit where cables are running use the method that best fi ts the conditions of the area in which you through the interior of the ceiling or wall. - Page 6 Embedding in the ceiling or wall Running cables on the exterior surface of the ceiling or Be sure to use the adapter ring when embedding the unit in the wall ceiling or wall. Drilling holes in the ceiling or wall To run cables on the exterior surface of the ceiling or wall, use the following procedure to attach the camera body.
- Page 7 Attaching the camera body Attach the camera body to the adapter ring. Remove the surface mount cover Please use the self-tapping screws from the camera body. included. Do not use any other Remove the body cover. screws. Attach the camera body to the adapter ring.
-
Page 8: Connecting The Cables
Connecting the cables Attention Connect the power cable and the LAN cable. When the power is supplied at the same time from the PoE power source Attention and the power cable, the power cable line is used. When the PoE power source is used, the connection of the power cable is Check if the power supply is “OFF.”... -
Page 9: Adjusting The Camera Direction
Installation of a microSD card Adjusting the camera direction The camera body is set in a tri-axial mounting allowing movement in When a microSD card that is sold separately is the pan, tilt, and rotational planes. used to save images, insert it into the microSD card slot. - Page 10 Adjusting the view angle and focus Installation and adjustment complete Move the lever to adjust focus and angle of view. Attach the body cover. Turn the inner cover. Then align the slit with the lens before attaching the dome cover. Focus adjustment lever / View angle adjustment lever When using ZN-D9922 or ZN-DN9922...
-
Page 11: Specifications
SPECIFICATIONS Digital Day/Night model Mechanical Day/Night model Model No. NTSC system (Service monitor output) ZN-D9024NHA ZN-D9312NHA ZN-D9922NHA ZN-DN9312NHA ZN-DN9922NHA Focal length (Wide to Tele) 2 mm - 4 mm 3.3 mm - 12 mm 9 mm - 22 mm 3.3 mm - 12 mm 9 mm - 22 mm Max. - Page 12 Digital Day/Night model Mechanical Day/Night model Model No. NTSC system (Service monitor output) ZN-D9024NHA ZN-D9312NHA ZN-D9922NHA ZN-DN9312NHA ZN-DN9922NHA Alarm function Input 1 line: No-voltage make contact input (3.3 V DC pull-up resistor built-in - short circuit current 0.4 mA) Output 1 line: Relay contact output (Maximum 30 V DC, 1 A - 125 V AC 0.3 A)
