ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual 1.2. How to set Settings can be made using the 5 buttons located in the webpage. Go to [Setup] ‐ [Video & Audio] – [Video input] and you can see the page of below. Click PREVIEW button to pop up the image view 1. Press the SET button. The Setup menu is displayed on the monitor screen. 2010/2‐1 03A.00 4 ...
Page 5
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual 2. Select a menu item using the Up and Down buttons. Place the cursor over a desired item. 3. Set up a selected item by using the Left and Right buttons. 4. To finish and save the settings, select 'EXIT' and press the SET button. NOTE : • An item with the icon also has sub‐menus. To select a sub‐menu, press the SET button. • An item with the ‐ ‐ ‐ icon has no sub‐menus available for selection. 2010/2‐1 03A.00 5 ...
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual 1.2.1. LENS This function is used to adjust the brightness of the screen. 1. When the SETUP menu screen is displayed on the screen, position the cursor to point to LENS using the Up and Down buttons. 2. Select the type of lens using the Left and Right buttons. ● DC : Select Auto Iris Lens When DC is selected, you can control screen brightness. The range of brightness control is between 1 and 70 (40 in case of WDR mode). Adjust the brightness appropriately for optimal ...
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual 1.2.2. EXPOSURE 1. When the SETUP menu screen is displayed select EXPOSURE using the Up and Down buttons. 2. Select the desired mode using the Left and Right buttons. ● SHUTTER : Select either auto or manual shutter. ‐ A.FLK : Select this when picture flicker is experienced, which can happen when there is a clash with the frequency of the installed lighting. ‐ ESC : Select this to control the shutter speed automatically. If ESC is selected, the shutter speed is automatically controlled according to the ambient illumination available. ‐ MANUAL : The shutter speed is controlled manually. NOTE : • To produce better results with A.FLK, do not use it in conjunction with the WDR mode on the BACKLIGHT menu. • When the SHUTTER is set to ESC, and the camera is set to Internal Synchronization, the picture ...
Page 8
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual ● SENS‐UP : When it is night or dark, the camera automatically detects the light level and maintains a clear picture if this mode is activated. ‐ OFF : Deactivates the SENS‐UP function. ‐ AUTO : Activates the SENS‐UP function. ● RETURN : Select this to save the changes in the EXPOSURE menu and return to the SETUP menu. NOTE : • If you press the SET button in 'AUTO' mode, You can adjust brightness by increasing or decreasing the shutter speed. (X2~X256) • Note that the higher the zoom level, the brighter the screen, but the more likely it is that an after‐image will appear. • Although Noise, Spots, and Whitish symptoms may occur in SENS‐UP operation when the zoom level is increased, this is normal. ...
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual 1.2.3. White Balance Use the White Balance function to adjust the screen colors. 1. Position the cursor to point to WHITE BAL on the SETUP menu screen, select using the Up and Down buttons. 2. Select a desired mode using the Up and Down buttons. ※ Select one of the following 5 modes, as appropriate. ● ATW : Select when the color temperature is between 1800°K and 10500°K ● INDOOR : Select when the color temperature is between 4500°K and 8500°K ● OUTDOOR : Select when the color temperature is between 1800°K and 10500°K. (sodium light inclusion) ● AWC SET : To obtain the optimum state under the current luminance levels, direct the camera to point toward a sheet of white paper and press the SET button. If the environment ...
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual 1.2.4. BACKLIGHT This camera is designed to deliver a clear and distinct image of both subject and background, even when the subject is backlit. 1. Position the cursor to point to BACKLIGHT on the SETUP menu screen using the Up and Down buttons. 2. Select the desired mode using the Left and Right buttons. ● WDR : When the image has simultaneous bright and dark areas, the Wide Dynamic Range makes both areas distinct. ● OFF : Deactivates the WDR function. ● BLC : Enables the user to directly select an area of a picture to activate and control. ● HLC (High Light Compensation) : If there is a high light installed in a limited environment such as an apartment parking garage or gas station entrance, removing the high light makes it possible to view car license plates efficiently. ...
Page 11
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual 3. Select the desired mode using the Left and Right buttons and press the SET button. Select 'BLC' to adjust the area to be Select 'WDR' to adjust the WDR enhanced by the WDR function. LIMIT. Select LOW, MIDDLE, or HIGH. NOTE : • The WDR cannot be used when MANUAL mode or A.FLK mode in the 'SHUTTER' menu is selected. ...
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual 1.2.5. DNR (Digital Noise Reduction) This function reduces the background noise in a low luminance environment. 1. When the SETUP menu screen is displayed, select 'DNR' using the Up and Down buttons. 2. Select a desired mode using the Left and Right buttons. ● OFF : Deactivates DNR. Noise is not reduced. ● ON : Activates DNR so that noise is reduced. 3. Set the DNR mode to 'ON' and press the SET button. The noise reduction level can now be adjusted. NOTE : • You cannot set the DNR to 'ON' or 'OFF' when the AGC mode in the EXPOSURE menu is 'OFF'. • When adjusting the noise reduction level in DNR mode, remember that the higher the level is set, the greater the reduction in noise level, but it also increases the possibility of ghosting. 2010/2‐1 03A.00 12 ...
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual 1.2.6. DAY/NIGHT Pictures can be displayed in either color or black and white. 1. When the SETUP menu screen is displayed, select 'DAY/NIGHT' using the Up and Down buttons. 2. Select the desired mode using the Left and Right buttons. ● COLOR : The picture is displayed in color. ● B/W : The picture is always displayed in black and white. ● AUTO : This camera has an IR Cut‐Filter and automatically changes to the appropriate mode according to lighting levels. To set up the switching time and switching speed for the AUTO mode press the SET button. ...
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual 1.2.7. IMAGE ADJ. 1. When the SETUP menu screen is displayed, select 'IMAGE ADJ.' using the Up and Down buttons. 2. Select the desired mode using the Left and Right buttons. ● FREEZE : View and capture a still image. ● V‐REV : Flips the picture vertically on the screen. ● H‐REV : Flips the picture horizontally on the screen. ● D‐ZOOM : Digitally zooms, the range is x1~x10. ● SHARPNESS : As this value is increased the picture outline becomes stronger and clearer. 2010/2‐1 03A.00 14 ...
Page 15
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual ● RETURN : Select this to save the settings for the IMAGE ADJ. menu and to return to the SETUP menu. Note : • When H‐REV or V‐REV is selected, any text in the picture also will be flipped horizontally or vertically. • If the SHARPNESS level is increased too high the picture may become distorted, or noise may generated. 2010/2‐1 03A.00 15 ...
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual 1.2.8. SPECIAL 1. When the SETUP menu screen is displayed, select 'SPECIAL' using the Up and Down buttons. 2. Select the desired mode using the Left and Right buttons. ● CAM TITLE : If a title is entered, the title appears on the monitor. ① When the SPECIAL menu screen is displayed, use the Up and Down buttons to point the cursor to 'CAM TITLE'. ② Set to 'ON' using the Left and Right buttons. NOTE: When the CAM TITLE menu is 'OFF', no title will be displayed on the monitor screen even if one has been entered. 2010/2‐1 03A.00 16 ...
Page 17
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual ③ Press the SET button. ④ Use the 4 directional buttons to move to a character, and select it by pressing the SET button. Repeat this action to enter multiple characters. Up to 15 alphanumeric characters can be used. • If the cursor is moved to CLR and the SET button pressed, all letters are deleted. To edit a letter, change the cursor to the bottom left arrow and press the SET button. Move the cursor over the letter to be edited, move the cursor to the letter to be inserted and then press the SET button. ⑤ Enter a title, move the cursor to 'POS' and press the SET button. The entered title appears on the screen. Select the position to display the title on the screen using the 4 directional buttons and press the SET button. When the position is determined, select 'END' and press the ...
Page 18
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual NOTE : • When using AC power at a 60Hz frequency Line‐Lock synchronization can be used. • When the power is DC 12V, the SYNC. menu is fixed to the 'INT' mode. ● MOTION DET: This camera displays an on‐screen message whenever motion is detected. ① When the SPECIAL menu screen is displayed, press the Up and Down buttons so that the cursor points to MOTION DET. ② Set up the function using the 4 directional buttons. ‐ SENSITIVITY : Select up to eight MD areas. When the SENSITIVITY value is high, motion detection sensitivity is increased to recognize small movements. ‐ AREA MODE : Determines whether to use the MD area selected in SENSITIVITY. ‐ SEL POS : Determines which of the 4 vertices of each MD area is to be used. ‐ YPOS : Determines the co‐ordinates of the vertical axis for SEL POS. ‐ XPOS : Determines the co‐ordinates of the horizontal axis for SEL POS. ...
Page 19
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual ① When the SPECIAL menu screen is displayed, press the Up and Down buttons so that the cursor points to 'PRIVACY'. ② Set up using the 4 directional buttons. ‐ AREA SEL : Up to 8 areas are selectable. ‐ AREA MODE : Determines whether to use the area selected in the AREA SEL, and the size and position of the area. ‐ MASK COLOR : Determine area color. Select Grey, Green, Red, Blue, Black or White. ‐ TRANSP : Determine the transparency of the selected area, the range is from 0 to 3. ‐ RETURN : Select this to save the PRIVACY menu settings and return to the SPECIAL menu. ● DIS (Digital Image Stabilizer) : This function mitigates picture movement caused by external factors, such as wind. ●...
Page 20
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual ‐ DISP CAM ID : Display the camera title on the top left corner of the screen. ● LANGUAGE : Select the appropriate menu language. ● RESET : Resets the camera settings to the factory defaults. ● RETURN : Select this to save the SPECIAL menu settings and return to the SPECIAL menu. 2010/2‐1 03A.00 20 ...
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual 1.2.9. EXIT Press the SET button in the EXIT menu to save the current settings and exit the SET menu. 2010/2‐1 03A.00 21 ...
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual 2.2. How to set Settings can be made using the 5 buttons located in the webpage. Go to [Setup] ‐ [Video & Audio] – [Video input] and you can see the page of below. 1. Press the SET button. Settings can now be made. The Setup menu is displayed on the monitor screen. 2. Select a menu item using the Up and Down buttons. Place the cursor over a desired item. 2010/2‐1 03A.00 24 ...
Page 25
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual 3. When the LEFT or RIGHT button is pressed, available values and modes are displayed in order. Please Keep pressing the button until you get to the mode you wish to operate. 4. Please select 'EXrr and then press the SETUP button to finish the setting. NOTE : • If appears at the mode you wish to operate, it means that there is a sub‐menu which can be selected by pressing the SETUP button. • If ‐ ‐ ‐ appears at the mode item, it means that there is no mode available to be selected. 2010/2‐1 03A.00 25 ...
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual 2.2.1. LENS This function is used to adjust the brightness of the screen. 1. When the SETUP menu screen is displayed on the screen, position the cursor to point to LENS using the Up and Down buttons. 2. Select the type of lens using the Left and Right buttons. ● DC : Select Auto Iris Lens When DC is selected, you can control screen brightness. The range of brightness control is between 1 and 70 (40 in case of WDR mode). Adjust the brightness appropriately for optimal ...
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual 2.2.2. SHUTTER Auto or manual control can be selected. 1. When the SETUP menu is on the screen, please position the arrow to point to 'SHUTTER' by using the UP and DOWN buttons. 2. Please select the shutter mode by pressing the LEFT or RIGHT button. ●FLK : Please select 'FLK' mode when flickering occurs on the screen, due to an imbalance between illumination and frequency. NTSC ModeI:1/100, PAL Model: 1/120 ●ESC : Auto control 01 that shutter speed can be achieved. When ESC mode is on, the speed is controlled automatically according to the brightness of the screen. ●MANUAL : The shutter speed can be controlled manually. 3. Please select 'MANUAL' mode if you wish to adjust the shutter manually. • You can select speed from '1/60' to '1/120,000' sec (NTSC Models), '1/50' to '1/120,000 (PAL Modals). 4. Please press the SETUP button when all the settings are complete. NOTE : • While using the internal synchronous system, if the shutter setting is on 'ESC' and the camera is directly facing a bright fluorescent light, the image on the screen can be adversely affected. Therefore please choose the installation location with care. ...
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual 2.2.3. WHITE BALANCE Use the White Balance function to adjust the screen colors. 1. Position the cursor to point to WHITE BAL on the SETUP menu screen, select using the Up and Down buttons. 2. Select a desired mode using the Up and Down buttons. ※ Select one of the following 5 modes, as appropriate. ● ATW (Auto Tracking White Balance) : Select when the color temperature is between 1800°K and 10500°K (eg, fluorescent light, outdoor, sodium vapor lamp inside tunnels) ● AWC (Auto White balance Control): Please press the SETUP button while the camera is directed at a piece of white paper to obtain the optimum state under current illumination. If the environment including the light source is changed you have to adjust the white balance again. ...
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual 2.2.4. BACKLIGHT When there is a strong backlight behind the object, clear images of the background as well as the object can still be obtained by using the BACKLIGHT function. 1. Please position the arrow to point to 'BACKLIGHT' on the SETUP menu by using the UP and DOWN buttons. 2. Please select the mode you wish to operate by pressing the LEFT or RIGHT button. ● HIGH : The gain increases from 0dB up to 42dB. ● MIDDLE : The gain increases from 0dB up to 30dB. ● LOW : The gain increases from 0dB up to 18dB. ● OFF : BACKLIGHT function does not operate. 2010/2‐1 03A.00 29 ...
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual 2.2.5. AGC 1. Please position the arrow to point to 'AGC' on the SETUP menu by using the UP and DOWN buttons. 2. Please select the mode you wish to operate by pressing the LEFT or RIGHT button. As the level of gain increases, the screen gets brighter and the level of noise also increases. ● HIGH : The gain increases or decreases within the range of 6cIB ‐ 42dB. ● MIDDLE: The gain increases or decreases within the range of 6cIB ‐ 3OdB. ● LOW : The gain increases or decreases within the range of 6dB‐18dB. ●OFF : The gain is fixed at 6dB. 2010/2‐1 03A.00 30 ...
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual 2.2.6. DNR (Digital Noise Reduction) This function reduces the background noise in a low luminance environment. 2. When the SETUP menu screen is displayed, select 'DNR' using the Up and Down buttons. 2. Select a desired mode using the Left and Right buttons. ● OFF : There is no reduction in noise level. ● LOW : There is a small reduction in noise level with almost no ghost image. ● MIDDLE: The most effective mode. There is a sufficient reduction in noise levels without causing much ghost imaging. ● HIGH : The level 01 noise is reduced greatly, however there is an increase in ghost imaging. 3. Set the DNR mode to 'ON' and press the SET button. The noise reduction level can now be adjusted. NOTE : • When AGC is turned off, DNR does not operate. • When adjusting the noise reduction level in DNR mode, remember that the higher the level is ...
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual 2.2.7. SENS-UP (Low illumination) SENS UP helps maintain a bright, clear screen image by automatically detecting changes in the level of light in low light level conditions. 1. Please position the arrow to point to ‘SENS UP’ on the SETUP menu by using the UP and DOWN buttons. 2. Please select the mode you with to operate by pressing the LEFT or RIGHT button. ● AUTO : Low light level auto mode ● OFF : The function does not operate NOTE : When SHUTTER is in the manual mode, SENS UP does not operate. When AGC is turned off, SENS UP does not operate. 3. Please press the SET UP button when all the settings are complete. NOTE : • The Maximum storage magnification in low light level movement situations can be adjusted by pressing the SETUP button in ‘AUTO’ mode. (X2 ~ X128) ...
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual 2.2.8. SPECIAL 1. Please position the arrow to point to ‘SPECIAL’ on the SETUP menu by using the UP and DOWN Buttons. 2. Please select the mode you wish to operate by pressing the UP or DOWN button. ● CAMERA ID : If the ID is input, the camera ID appears on the monitor. 1) Please position the arrow to point to ‘CAMERA ID’ by using the UP or DOWN button. 2) Please select ‘ON’ by pressing the LEFT or RIGHT nutton. NOTE : If ‘OFF’ is selected, the ID does not appear on the monitor even if it has been input. 3) Please press the SETUP button. 4) Up to 15 letters can be used for the ID. ①...
Page 34
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual ③ Please lock in the letters by using the SETUP button (When the letter is locked in, the cursor moves to the next space. ④ Please repeat the above to input the ID. NOTE : If the wrong name has been input… If you press the SETUP button after moving the cursor to CLR, all the letters will be erased. IF you want to the arrow at the bottom left of the screen and press ‘SET’. Position ...
Page 35
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual ‐ AUTO : This camera has a function which automatically changes to the appropriate mode for daytime or night‐time. The COLOR mod is operated for daytime, and it converts to BW mode for night‐time. ‐ ON : The color mode is selected by default, and the modes do not change automatically. NOTE : • When the AGC is turned off, COLOR does not operate. • When an infrared light is used, there may be a problem with focusing. ● SYNC : Two of synchronization modes are available Internal and External line‐lock mode, it synchronizes the video signal between cameras without a synchronous generator. The line‐ lock synchronization is only used In the areas of 60Hz and 50Hz. ‐ INT : Internal Synchronization Type ‐ L/L : Power Synchronization Type, Line‐lock • Press the SET button. • Select a phase between 0 and 359. NOTE : • When using AC power at a 60Hz frequency Line‐Lock synchronization can be used. • When the power is DC 12V, the SYNC. menu is fixed to the 'INT' mode. ...
Page 36
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual 5. Adjust the level of observation by using SENSITIVITY mode. 6. Press the SETUP button to save the changes and complete the setting. ●PRIVACY This mode conceals the areas you do not want to appear on the screen. ‐ OFF: Cancels the PRIVACY mode. ‐ ON : Operates the PRIVACY mode. 1. Press the SETUP mode 2. Select the area you do not want to appear from the 4 areas in AREA SEL mode. 3. Select ON mode for the chosen area 4. Adjust the size of the area to be concealed by using the UP, DOWN, LEFT or RIGHT button. ...
Page 37
ZN‐DT350VE/ZN‐DNT350VE/ZN‐DWNT350VE OSD Menu Control Manual ‐ OFF : Cancels the inversion ● SHARPNESS The outline of the video image becomes cleaner and more distinctive as the level of SHARPNESS increases. If the level goes up excessively, however, it may affect the video image and generate noise. 1. Press the SEUP button 2. Set the available range of level from 0 to 31. ● RESET Return to the level which was set by the manufacturer for shipment. ●RETURN Saves the SPECIAL menu and returns to the SETUP menu. 2010/2‐1 03A.00 37 ...
