DEVICE SETUP

2.1 Quick Start

Follow the steps below to use the OWC Drive Guide utility to format your Mercury Elite Pro Dual for Mac (OS X
10.6 and later) or Windows (XP and later). If you installed your own drives, please use the formatting method you
are most familiar with or check Section 3.1 for a link to our online formatting tips.
1. Power on the Mercury Elite Pro Dual and plug it into to your computer using the proper data cable. If you prefer
to use a different formatting utility, do so at this time and skip the rest of these steps.
2. The disk will mount and your operating system will display it as "OWC SETUP". Open the disk icon to view its
contents.
3. Double-click the OWC Drive Guide application.
4. Follow the simple on-screen instructions to complete the formatting process. Once the formatting is finished
the drive is ready to use.

2.2 Assembly

NOTE: these assembly instructions are written for users who purchased the Mercury Elite Pro Dual as an empty
enclosure. The instructions show how to open the enclosure in order to install drives. If you purchased the
Mercury Elite Pro Dual with drives already installed, opening the enclosure before the expiration of the original
the warranty. If you wish to remove or replace the drives after the expiration of the original
warranty will VOID
warranty, you may do so at that time. You should start with Step 9 in that case and work backwards.
1. Remove the Mercury Elite Pro Dual from its packaging,
then set the enclosure on its side. Use a Phillips PH2
driver to remove the two screws shown at right.
2. Slide the inner chassis out the front of the outer
enclosure, as shown at left. Start by pushing on
the back cover, then grip the front grill and pull the
chassis the rest of the way.
