CAP 232-46N
CAP 232-46N
Requires :
Wing Span
Wing Area
Flying Weight
Fuselage Length
Warning ! This model is not a toy.
It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of engine powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
A198NPO26411108
0.46-
0.55
cu.in. displacement 2-stroke
-
0.70 0.81 cu.in. displacement 4-stroke
4 - channels radio w
Specifications
* Specifications are subject to change without notice.*
Ltd
INSTRUCTION MANUAL
5 standard servos
/
56.5 in /1440 mm
496 sq in / 32 sq dm
5.5 lb / 2500 g
50 in / 1270 mm
ALMOST-READY-TO-FLY (ARF) SERIES
FACTORY PRE-FABRICATED
MADE IN CHINA
Advertisement
Related Manuals for The World Models Manufacturing CAP 232-46N
Summary of Contents for The World Models Manufacturing CAP 232-46N
- Page 1 INSTRUCTION MANUAL CAP 232-46N CAP 232-46N Requires : 0.46- 0.55 cu.in. displacement 2-stroke 0.70 0.81 cu.in. displacement 4-stroke 4 - channels radio w 5 standard servos Specifications Wing Span 56.5 in /1440 mm Wing Area 496 sq in / 32 sq dm Flying Weight 5.5 lb / 2500 g...
