Parts List

1. MAIN WING -- 1 pair
2. SCREW PB2x22mm -- 6 pcs
FUEL TUBE Ø6x5mm -- 4 pcs
CLEVIS -- 2 pcs
STRAPER -- 2 pcs
TRI-HORN M3x14mm (S) -- 2 sets
PUSHROD Ø1.8x130mm w/ Threads (For Aileron) -- 2 pcs
3. STABILIZER & ELEVATOR -- 1 set
FUESLAGE -- 1 pc.
4. VERTICAL FIN & RUDDER -- 1 set
5. TAIL LANDING GEAR -- 1 set
SCREW PA3x12mm -- 2 pcs
COLLAR Ø2.1mm w/ set screw -- 1 set
WHEEL Ø25mm -- 1 pc.
6. MAIN LANDING GEAR -- 1 pair
WHEEL PANTS -- 1 pair
SCREW HM4x35mm -- 2 pcs
M4 NUT -- 2 pcs
SCREW PA2.6x6mm -- 4 pcs
SOCKET HEAD SCREW M2.5x12mm -- 6 pcs
WASHER d2.5xD8mm -- 6 pcs
WASHER d4.5xD9mm -- 4 pcs
WASHER d3xD7mm -- 4 pcs
WHEEL Ø55mm -- 2 pcs
COLLAR Ø4.1mm w/ set screw -- 4 sets
PLATE 1mm -- 1 pair
7. SCREW PM2x25mm -- 3 pcs
M2 NUT -- 3 pcs
FUEL TUBE Ø6x5mm -- 2 pcs
CLEVIS -- 2 pcs
TRI-HORN M3x14mm (S) (w/ o-Basa For Rudder) -- 2 sets
RIGGING COUPLER Ø1.8x27mm w/ Threads (For Rudder) -- 2 pcs
COPPER TUBE d2.5xD3.2x8mm (For Rudder) -- 2 pcs
WIRE Ø1x880mm (For Rudder) -- 2 pcs
8. SCREW PB2x20mm -- 6 pcs
FUEL TUBE Ø6x5mm -- 2 pcs
CLEVIS -- 2 pcs
TRI-HORN M3x14mm (S) -- 2 sets
PUSHROD Ø1.8x680mm w/ Threads (For Elevator) -- 2 pcs
9. ENGINE MOUNT PL5111050 -- 1 set
SOCKET HEAD SCREW M4x22mm -- 4 pcs
WASHER d4xD9mm -- 4 pcs
10. FUEL TANK 320cc -- 1 set
BALSA 8x8x89mm (For Fuel Tank Position Fixing) -- 1 pc.
RUBBER BAND -- 2 pcs
11. SCREW HM3.5x30mm -- 4 pcs
M3.5 NUT -- 8 pcs
WASHER d3.5xD8mm -- 8 pcs
THROTTLE PUSHWIRE Ø1.2x370mm -- 1 set
PLASTIC TUBE d2xD3x185mm -- 1 pc.
12. LINKAGE CONNECTOR Ø2.1mm -- 1 set
13. FUEL TUBE Ø6x5mm -- 1 pc.
STRAPER -- 1 pc.
PUSHROD CONNECTOR -- 1 set
POSHROD Ø1.8x112mm (For Elevator Servo) -- 1 pc.
COPPER TUBE d2.5xD3.2x8mm (For Rudder) -- 2 pcs
RIGGING Z BEND Ø1.8x27mm (For Rudder) -- 2 pcs
PLYWOOD 5x61x89.5mm (For Rudder Servo) -- 1 pc.
BALSA 6x6x61mm (For Rudder Servo Stand) -- 2 pcs
SPONGE 10x80x200mm -- 2 pcs
14. SCREW PWA2.6x12mm -- 4 pcs
SILICON GROMMET d1.5xD6.5mm -- 4 pcs
COWLING -- 1 set
TRANSPARENT 3D TEMPLATE -- 1 pc.
SPINNER Ø57mm -- 1 set
15. SCREW HM3x18mm -- 1 pc.
SCREW PA3x18mm -- 1 pc.
WASHER d3xD7mm -- 2 pcs
WING TUBE d14xD16x595mm -- 1 pc.
16. CANOPY -- 1 pc.
SCREW PWA2.3x8mm -- 4 pcs
SCREW HM3x16mm -- 2 pcs
SILICON GROMMET d1.5xD6.5mm -- 4 pcs
WASHER d3xD7mm -- 2 pcs
DOUBLE-SIDED TAPE -- 1 pc.
17. DECALS:A189DEC -- 1 set
COVERING:--
TOUGHLON STL100 WHITE
TOUGHLON STL360 VIOLET
TOUGHLON STL361 PURPLE
TOUGHLON STL511 PEARL FERRARI RED
TOUGHLON STL550 PEARL BLUE
TOUGHLON STL561 PEARL PURPLE
P.2
