Before commencing assembly, please read these instructions thoroughly.
CAP 232 46S
CAP 232 46S
Wing Span: 56.5 in /1440 mm
Wing Area: 496 sq in / 32 sq dm
Flying Weight: 5.5 lbs / 2500 g
Fuselage Length: 50 in / 1270 mm
Required : 2-stroke 0.46 or 4-stroke 0.70 engine
Warning ! This model is not a toy.
It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of engine powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
* Specifications are subject to change without notice.*
THE WINGS MAKER
FACTORY PRE-FABRICATED
ALMOST-READY-TO-FLY (ARF) SERIES
MADE IN CHINA
www.thewingsmaker.com
GA012SPO27831211
Specifications
Specifications
4- channel radiow/ 5 servos
INSTRUCTION MANUAL
Advertisement
Table of Contents
Related Manuals for The Wings Maker CAP 232 46S
Summary of Contents for The Wings Maker CAP 232 46S
- Page 1 INSTRUCTION MANUAL Before commencing assembly, please read these instructions thoroughly. CAP 232 46S CAP 232 46S Specifications Specifications Wing Span: 56.5 in /1440 mm Wing Area: 496 sq in / 32 sq dm Flying Weight: 5.5 lbs / 2500 g Fuselage Length: 50 in / 1270 mm Required : 2-stroke 0.46 or 4-stroke 0.70 engine...
-
Page 2: Before You Begin
CAP 232 46S CAP 232 46S I N D E X BEFORE YOU BEGIN P. 1 PARTS LIST P. 2 ASSEMBLY P. 3 -P.10 SAFETY PRECAUTIONS P. 10 BEFORE YOU BEGIN Read through the manual before you begin, so you will have an overall idea of what to do. -
Page 3: Parts List
Parts List 1. MAIN WING -- 1 pair 11. ENGINE MOUNT PL5111050 -- 1 set SOCKET HEAD SCREW M4x25mm -- 4 pcs 2. PLYWOOD 6x31x204mm(Wing Joiner) -- 1 pc. WASHER d4xD9mm -- 4 pcs 3. SCREW PB2x20mm -- 6 pcs 12. -
Page 4: Aileron Servo
Main Wing Bottom View Apply instant type CA glue to both sides of each hinge. Main Wing Wing Joiner 6x31x204mm Aileron Servo Lead Apply glue to both sides of all surfaces in contact. Use a stick to apply glue to inner side of wing joiner sleeve, and apply glue to wing joiner before putting them together. -
Page 5: Tail Landing Gear
Stabilizer / Elevator (Stabilizer) Temporary install the main wing, adjust leveling of the stabilizer to make it as Apply instant type CA glue to (Main Wing) parallel to the main wing as possible. both sides of each hinge. B B' *Also refer to step 18 Wing Setting A=A' Remove coverings for all surfaces in... -
Page 6: Elevator Pushrod
Rudder Pushrod Ø1mm pilot holes for The Wings Maker tri-horn are pre-drilled. Please look for pin-hole marks at side of control surfaces. Screw PB2x16mm Rudder Pushrod 1.8x620mm Fuel Tube Clevis Ø 6 x 5mm Metal Rod Ø 1.8x 620mm PB2x16mm... -
Page 7: Engine Mount
Fuel Tank Double_side Tape Cable Tie 40x100mm 1.5x5x400mm Fuel Tank 260cc Completed Engine Mount Apply thread locker to screws. M4x25mm Socket Head Screw Washer d4xD9mm d4xD9mm Washer Engine Mount PL5111050 Blind nuts are off-centered to keep the spinner at the fuselage axis. Servo Set LINKAGE CONNECTOR Set Screw... -
Page 8: Radio Equipment
Engine M4x25mm Socket Head Screw Install Engine Position 132mm M3 Nut 5.2 in. Washer d3xD7mm d3xD7mm Washer Throttle Pushwire Ø1.2x410mm Plastic Tube d2xD3x280mm d3xD7mm M 3x25mm Washer Radio Equipment Install and arrange the servo as shown in the diagram. BALSA Rudder Servo Front Rudder pushrod... - Page 9 Main Wing Screw HM 4x30mm Washer d4.2xD14.5mm Wing Protection 2x30x92mm d4.2xD14.5mm HM4x30mm Washer Cowling First insert the grommet to the cowling then apply screw. Screw PWA2.6x12mm d1.5 x D6.5 mm Silicon Grommet Spinner 1.5mm Silicon Grommet d1.5xD6.5mm PWA2.6x12mm Fuselage Cowling Canopy First insert the grommet to the canopy then apply screw.
- Page 10 Wing Setting A = A ' B = B ' C = C ' GA012SPO27831211...
- Page 11 # Pre-flight adjustment must be done before flying, it is very dangerous to fly a badly pre-adjusted aircraft. CAP 232 46S CAP 232 46S is specially designed to be powered by 2C 0.46 or 4C 0.70 engine, using a more powerful engine does not mean better performance.
- Page 12 Add washer to reduce play if necessary. Shoulder Tighten up the round nut against the shoulder. Apply CA or permanent thread locker. After fastening the round nut, make sure that the linkage connector can rotate freely. THE WINGS MAKER GA012SPO27831211...
