Instruction Manual
Before commencing assembly, please read these instructions thoroughly.
FAIRCHILD PT-26 40
FAIRCHILD PT-26 40
Wing Span: 57.5 in / 1460 mm
Wing Area: 533 sq in / 34.4 sq dm
Flying Weight: 5.3 Ibs / 2400 g
Fuselage Length: 44 in / 1120 mm
Requires: 2-stroke 0.40 or
Warning ! This model is not a toy.
It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of engine powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
* Specifications are subject to change without notice.*
THE WINGS MAKER
FACTORY PRE-FABRICATED
ALMOST-READY-TO-FLY (ARF) SERIES
MADE IN CHINA
www.thewingsmaker.com
GA021SPO27821210
Specifications
Specifications
4-stroke 0.52 engine
4-channel radio w/ 5 servos
INSTRUCTION MANUAL
( GA021 )
Advertisement
Table of Contents
Related Manuals for The Wings Maker FAIRCHILD PT-26 40
Summary of Contents for The Wings Maker FAIRCHILD PT-26 40
- Page 1 INSTRUCTION MANUAL Before commencing assembly, please read these instructions thoroughly. FAIRCHILD PT-26 40 FAIRCHILD PT-26 40 ( GA021 ) Specifications Specifications Wing Span: 57.5 in / 1460 mm Wing Area: 533 sq in / 34.4 sq dm Flying Weight: 5.3 Ibs / 2400 g Fuselage Length: 44 in / 1120 mm Requires: 2-stroke 0.40 or...
- Page 2 FAIRCHILD PT-26 40 FAIRCHILD PT-26 40 I N D E X BEFORE YOU BEGIN P. 1 PARTS LIST P. 2 ASSEMBLY P.3-10 SAFETY PRECAUTIONS P.10 BEFORE YOU BEGIN Read through the manual before you begin, so you will have an overall idea of what to do.
- Page 3 Parts List 10.FUEL TANK 320cc -- 1 set 1. MAIN WING -- 1 pair CABLE TIE 1.5x5x400mm -- 1 pc. DOUBLE-SIDE TAPE 40x100mm -- 1 pc. 2. WOODEN WING JOINER 9x21.8x124mm -- 1 pc. 11.ENGINE MOUNT PL5111050 -- 1 set MAIN LANDING GEAR -- 1 set SOCKET HEAD SCREW M4x25mm -- 4 pcs SCREW PA3x14mm -- 8 pcs...
-
Page 4: Main Landing Gear
Main Wing Aileron Servo Lead Pre-glued Bottom View Main Wing Apply glue to both sides of all surfaces in contact. Use a stick to apply glue to inner side of wing joiner sleeve, and apply glue to wing joiner before putting them together. - Page 5 Aileron Servos Ø1mm pilot holes for The Wings Maker tri-horn are pre-drilled. TWM PL8210010 Please look for pin-hole marks at under side of control surfaces. CLEVIS WRENCH PWA 2 x 8mm Clevis PB2x16mm Screw 1.5mm Fuel Tube Ø6x5mm PWA2x8mm Screw Pushrod Ø1.8x115mm...
-
Page 6: Rudder Pushrod
Screw PA3 x 12mm Collar 2.1mm WHEEL Collar Set Screw Ø1mm pilot holes for The Wings Maker tri-horn are pre-drilled. Rudder Pushrod Please look for pin-hole marks at side of control surfaces. PB2 x16mm Screw Fuel Tube Clevis PB2x16mm Rudder Pushrod 1.8x640mm... -
Page 7: Fuel Tank
Fuel Tank Cable Tie 1.5x5x400mm Double-side Tape 40x100mm Completed Engine Mount Apply thread locker to screws. M4x25mm Socket Head Screw Washer d4xD9mm M4x25mm Washer d4xD9mm Engine Mount PL5111050 Blind nuts are off-centered to keep the spinner at the fuselage axis. Servo Set LINKAGE CONNECTOR Set Screw... -
Page 8: Radio Equipment
Engine Install Engine Position 120mm 4.7in. M3x30mm Socket Head Screw Washer d3xD7mm Throttle Pushwire Plastic Tube Ø1.8x400mm d2xD3x270mm M3 NUT Washer d3xD7mm M3 x 30mm Radio Equipment Install and arrange the servo as shown in the diagram. Rudder Pushrod Front Battery Rudder Servo Elevator Servo... - Page 9 Main Wing Screw HM 4x35mm Washer d4xD15mm Wing Protection 3x34x107mm Washer d4xD15mm HM4x35mm Cowling First insert the grommet to the cowling then apply screw. Please refer to the attached sheet for usage of the transparent 3D template. Screw PWA2.6x12mm d1.5 x D6.5 mmSilicon Grommet Spinner Nut 1.5mm Fuselage...
- Page 10 Wing Setting Adjust the wing and fuselage configuration as shown in the diagrams. A’ B’ C’ A=A’ B=B’ C=C’ GA021SPO27821210...
-
Page 11: Control Throws
# First time flyer should never fly by himself / herself. Assistance from experienced flyer is absolutely necessary. # Pre-flight adjustment must be done before flying, it is very dangerous to fly a badly pre-adjusted aircraft. FAIRCHILD PT-26 40 FAIRCHILD PT-26 40 is specially designed to be powered by 2 C 0.40 or 4 C 0.52 engine, using a more... - Page 12 THE WINGS MAKER GA021SPO27821210...
