Before commencing assembly, please read these instructions thoroughly.
Wing Span: 39.5 in / 1000 mm
Wing Area: 257 sq in / 16.6 sq dm
Flying Weight: 26 oz / 740 g
Fuselage Length: 32.5 in / 830 mm
Requires: 4- channel radio w/ 4 micro servos,
Warning ! This model is not a toy.
It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of electric powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
* Specifications are subject to change without notice.*
THE WINGS MAKER
FACTORY PRE-FABRICATED
ALMOST-READY-TO-FLY (ARF) SERIES
MADE IN CHINA
www. thewingsmaker. com
Specifications
Specifications
15A speed controller
and 8 cells 1000 mAh battery.
INSTRUCTION MANUAL
GE017
Advertisement
Table of Contents
Related Manuals for The Wings Maker Spitfire EP
Summary of Contents for The Wings Maker Spitfire EP
-
Page 1: Instruction Manual
Operating this model without prior preparation may cause injuries. Remember, safety is the most important thing. Always keep this instruction manual at hand for quick reference. * Specifications are subject to change without notice.* THE WINGS MAKER FACTORY PRE-FABRICATED ALMOST-READY-TO-FLY (ARF) SERIES MADE IN CHINA www. -
Page 2: Before You Begin
I N D E X BEFORE YOU BEGIN PARTS LIST ASSEMBLY P.3-9 SAFETY PRECAUTIONS BEFORE YOU BEGIN Read through the manual before you begin, so you will have an overall idea of what to do. Check all parts. If you find any defective or missing parts contact your local dealer. Please DRY FIT and check for defects for all parts that will require CA or Epoxy for final assembly. - Page 3 Parts List COVERING LIGHTEX SGX203 LIGHT GRAY LIGHTEX SGX340 OLIVE DRAB...
- Page 4 Main Wing Aileron Servo Lead Bottom View Apply instant type CA glue to both sides of each hinge. Aileron Servos Screw PM2x16mm straper Ø1mm pilot holes for The Wings Maker horn are pre-drilled. Please look for pin-hole marks PM2x16mm at under side of control surfaces. Fuel Tube d2xD4X4mm Clevis...
- Page 5 Temporary install the main wing, adjust leveling of the stabilizer to make it as (Stabilizer) Screw PM2x8mm B´ parallel to the main wing as possible. (Main Wing) B=B´ *Also refer to step 13 Wing Setting Completed Ø1mm pilot holes for The Wings Maker tri-horn are pre- PM2x8mm...
-
Page 6: Tail Landing Gear
Tail Landing Gear PA2x8mm Screw PA2x8mm PA2 x 8mm Wheel Ø23mm PM2x6mm Screw 2. 6mm Collar M2mm Nut Plastic Collar M2 Nut PM2x6mm Rudder Pushrod PM2 x 8mm Screw Fuel Tube d2xD4x4mm Horn Pushrod Ø1.4x430mm Clevis PM2 x 8mm Bottom View Elevator Pushrod Pushrod Ø1.4x423mm... -
Page 7: Radio Equipment
Motor / Cowling Socket Head Screw M2.6 x 7mm Screw PM2 x 12mm Screw PWA2 x 8mm PA2.6 x 8mm Screw PM2 x 12mm Speed 400 Motor Washer d2 x D5mm Set Screw M2.6 x 7mm M2 Nut Washer d2 x D5mm PM2 x 12mm PM2 x 12mm Ø45mm... -
Page 8: Main Landing Gear
Main Wing M2.5x20mm Nylon Bolt d2.6x D9mm Nylon Washer M2.5 x 20mm Plywood 2x20x55mm d2.6 x D9mm Nylon Washer M2.5x20mm d2.5x D8mm Nylon Washer Main Landing Gear Screw PA2.3x12mm Mounting PA2.3x12mm Plate Collar 2.6mm 46mm 1.5mm 57mm 2.6mm Collar 3mm Set Screw Canopy PWA2 x 8mm Screw... - Page 9 Wing Setting Adjust the wing and fuselage configuration as shown in the diagrams. A´ C´ B´ C =C ' A =A ' B =B '...
-
Page 10: Control Throws
Control Throws Adjust the control throws as shown in the diagram. These throws are good for general flying. You can adjust according to your personal preference. Rudder 20mm 20mm Elevator 10mm 10mm Aileron The ideal C.G. position is 60mm (2.36 in.) behind C.G. - Page 11 THE WINGS MAKER GE0170612...
