Before commencing assembly, please read these instructions thoroughly.
Wing Span: 78 in /1980mm
Wing Area: 665 sq in / 42.9 sq dm
Flying Weight: 39 oz / 1100g
Fuselage Length: 40 in / 1020mm
Required : speed 550 motor, 3-channel radio
Warning ! This model is not a toy.
It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of electric power precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
* Specifications are subject to change without notice.*
THE WINGS MAKER
FACTORY PRE-FABRICATED
ALMOST-READY-TO-FLY (ARF) SERIES
MADE IN CHINA
www.thewingsmaker.com
Specifications
Specifications
w/ 2 mini servos, 25A speed controller
with brake and 7 cells 1800 mAh battery
INSTRUCTION MANUAL
GE020
Advertisement
Table of Contents
Related Manuals for The Wings Maker Blue Bird EP
Summary of Contents for The Wings Maker Blue Bird EP
- Page 1 Operating this model without prior preparation may cause injuries. Remember, safety is the most important thing. Always keep this instruction manual at hand for quick reference. * Specifications are subject to change without notice.* THE WINGS MAKER FACTORY PRE-FABRICATED ALMOST-READY-TO-FLY (ARF) SERIES MADE IN CHINA GE020 www.thewingsmaker.com...
-
Page 2: Safety Precautions
I N D E X BEFORE YOU BEGIN PARTS LIST ASSEMBLY P.3-9 SAFETY PRECAUTIONS BEFORE YOU BEGIN Read through the manual before you begin, so you will have an overall idea of what to do. Check all parts. If you find any defective or missing parts contact your local dealer. Please DRY FIT and check for defects for all parts that will require CA or Epoxy for final assembly. - Page 3 Parts list 1. MAIN WING--1 set 7 SPONGE 10x50x150mm--1 pc. WING JOINER Ø6x226mm--1 pc. DOUBLE-SIDED TAPE(30x35mm)--1 pc. BATTERY TIE--1 pc. 2. STABILIZER & ELEVATOR--1 set STRAPER--2 pcs 3. VERTICAL FIN & RUDDER--1 set FUEL TUBE d2xD4x4mm--2 pcs 4. PUSHROD Ø1.4x695mm w / Threads(For Elevator)--1 pc. 8.
-
Page 4: Stabilizer & Elevator
Main Wing Wing joiner Ø6x 226mm Completed Stabilizer & Elevator Apply instant type CA glue to both sides of each hinge. Bottom View Temporary install the main wing, adjust (Stabilizer) leveling of the stabilizer to make it as parallel to the main wing as possible. (Main Wing) A A' *Also refer to step 10 Wing Setting... - Page 5 Vertical Fin & Rudder Apply instant type CA glue to both sides of each hinge. Peel off shaded portion covering film. Completed...
-
Page 6: Elevator Pushrod
PM2 x 10mm Pushrod D1.4 x 630mm Pushrod PM2 x 10mm D1.4 x 630mm Horn Clevis Fuel Tube d2xD4 x 4mm Ø1mm pilot holes for The Wings Maker tri-horn are pre-driled. Please look for pin-hole marks at side of control surfaces. - Page 7 Motor / Cowling Setting M3 x 8mm Socket Head Screw Screw x 12mm Screw PM x 1 mm Screw PWA2 x 8mm Screw PA2.6 x 8mm M2.5 x 12mm Washer d2.5 x D8mm Washer d3 x D7mm Set Screw M3 x 8mm Washer d3 x D7mm Washer...
-
Page 8: Radio Equipment
Radio Equipment Install and arrange the servo as shown in the diagram. Rudder Servo Battery Speed 550 Motor Front Rudder Pushrod Fuel Tube Ø4 x 4mm Straper Receiver Sponge Battery Tie Double-Side Tape Elevator Pushrod 25A Speed Controller Elevator Servo Main Wing Screw PM2.5 x 16mm... - Page 9 Wing Setting A=A' B=B' C=C'...
-
Page 10: Control Throws
Control Throws Rudder 30mm 30mm Elevator 15mm 15mm The ideal C.G. position is 75mm (2.95 in.) Behind the leading edge C.G. measured at where the wing meets the fuselage. In order to obtain the C.G.specified, add weight to the fuselage or move the battery position. - Page 11 THE WINGS MAKER P.10 GE0200611...
