4.5 SCRs and SCR Connections
Models MCD5-0021B - MCD5-0245C use SCRs. Each soft starter requires three SCRs.
4
4
175G5119 - 175G5122
NOTE
Spare part kits may onclude either Semikron or Eupec SRCs.
These SCRs are fully interchangeable in MCD 500 units and
can be mixed within the same soft starter.
Model 0021 - 0068
22
MCD 500 Service Manual
MCD5-0021B
MCD5-0037B
MCD5-0043B
MCD5-0053B
MCD5-0068B
MCD5-0084B
MCD5-0089B
MCD5-0105B
MCD5-0131B
MCD5-0141B
MCD5-0195B
MCD5-0215B
MCD5-0245C
175G5123, 175G5124, 175G5634
MG.17.L4.02 - VLT
7 6
5 4
SEMIKRON
®
is a registered Danfoss trademark
175G5119
175G5120
175G5121
175G5122
175G5123
175G5124
175G5634
175G5635
175G5126
175G5127
175G5635, 175G5126, 175G5127
7 6
5 4
EUPEC
