Mcd5-0131B - Mcd5-0215B (G2B) - Danfoss MCD500 Service Manual

Service Instructions

3.1.3 MCD5-0131B - MCD5-0215B (G2B)

3 3
1
1
2
3
4
5
6
7
14
MCD 500 Service Manual
2 3 4
Cover
Main plastic
Cable guide
Terminal blocks
LCP and Main Control PCB
Bypass Driver PCB
Support plastic
MG.17.L4.02 - VLT
7 8
5 6
8 Model PCB
9 Current transformers
10 Bypass contactors
11 SCRs
12 Main body
13 Fan and bracket
®
is a registered Danfoss trademark
9 10 11 12
177HA538.10
13
