3.1 Frame Sizes

The physical layout and spare parts for MCD 500 vary
according to the size of the starter. MCD 500 starters can be
grouped into five classes ("frame sizes") as follows:
Class MCD 500 Models
G1B MCD5-0021B
MCD5-0037B
MCD5-0043B
MCD5-0053B
MCD5-0068B
MCD5-0084B
MCD5-0089B
MCD5-0105B
G2B MCD5-0131B
MCD5-0141B
MCD5-0195B
MCD5-0215B
G3C MCD5-0245C
G4C MCD5-0360C
MCD5-0380C
MCD5-0428C
MCD5-0595C
MCD5-0619C
MCD5-0790C
MCD5-0927C
G5C MCD5-1200C
MCD5-1410C
MCD5-1600C
