Service Instructions
3.1.2 MCD5-0068B - MCD5-0105B (G1B)
1
2
1
Cover
2
Cable guide
3
Main plastic
4
Terminal blocks
5
LCP and Main Control PCB
6
Model PCB
7
Current transformers
MCD 500 Service Manual
3
4
5
6
7
8
9
10
11
12
13
®
MG.17.L4.02 - VLT
is a registered Danfoss trademark
8
9
10
11
177HA537.10
Mounting posts
Bypass contactors
Backplane PCB
SCRs
Side plastic
Fan
12
13
13
3
3
